Working Voltage: AC 220V 50Hz
Load power: Incandescent lamp ≤ 100W CFL ≤32W
Sensing range: 180x360 °
Sensing range: ≤ 8m
Size:50x36x25mm
Install cable length: 16cm
Ambient temperature: -20 ° ~ + 50 °
Their power consumption: ≤0.2W
Delay time: 30 seconds
Sensitivity: 7LUX
Detection speed: 0.6-1.5 m / sec

# 220V AC 50Hz Auto Infrared Sensor Switch Feature:
Radar switch sensing distance far enough, wide angle, no dead zone, can penetrate glass, and thin wood, depending on the power and can penetrate walls of different thicknesses, from the environment, temperature, dust and other effects, in the case of more than 37 degrees , the sensing range is not shortened, the temperature sensing distance becomes constant. I hope sensing angle a
small point, you can set the switch sides of the metal obstruction, or choose our restaurant infrared body sensor switch. Radar can pass through walls of 25cm hollow home.

1. Smart sensor: When someone enters the detection range of the product, the microwave detector operating point lights when people leave the detection range, the light automatically goes off. It can automatically identify day and night.
2. Smart delay: switch after detecting the human body every activity will be automatically extended cycle, and extended time of the last human activities as the starting point.
3. Work: After induction switch is turned on, the delay period, if human activity, the switch will continue on until people leave and extended time. The photosensitive control: according to the outside light intensity, to control the switch is working to achieve energy savings.
4. Adjustable delay: clockwise, counterclockwise adjustment, 15-30 seconds.

Use: hallway, corridor, basement, garage, storage, monitoring and other indoor (outside) energy-saving automatic lighting
situations

# 220V AC 50Hz Auto Infrared Sensor Switch Note:
1. Disable charged install and operate, load short circuit is strictly prohibited. (Be sure to regulate their own power before
the switch, or peril)
2. Do not exceed the load power usage.
3. When the wall thickness of less than 10 cm, the switch is likely to partition induction.
4. In the sensitive area, do not affect its non-stop movement of an object or obstacle detection.
5.When install, metal objects blocking the sensor is prohibited.

# 220V AC 50Hz Auto Infrared Sensor Switch Package included:
1x Infrared radar switch
