0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
0.032inch 3003 Aluminum Alloy Metal Sheet Strip
Specifications
Brand Name :
DZSICO
Model Number :
5005, 5052, 5083, 5754
Certification :
SGS, ISO9001:2008
Place of Origin :
CHINA
MOQ :
3 Tons
Price :
$2,980.00 - $3,600.00 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000 Ton/tons Per Month 3003 Aluminum Strips
Delivery Time :
1-10T - 7Days, 11-25T - 10Days, 26-100 - 10Days, > 100-To be negotiated
Packaging Details :
Standard Seaworthy Package Or As Customers Requirement
Grade :
3000 Series
Temper :
O - H112
Type :
Plate
Application :
Automobile
Width :
100mm to 2600mm
Surface Treatment :
Coated
Alloy Or Not :
Is Alloy
Surface :
Mill Finish
Chemcial :
ANTI - RUST
Description

Price Of Aa 3003 Aluminum Alloy Metal Sheet Strip, 0.032 Thick Or Gauge

Aluminum alloy 3003 contains about 1.25% manganese and 0.1% copper, which increase the strength approximately 20% above the 1000 series aluminum grades. this is often the foremost widely used of all aluminum alloys and it's all the superb characteristics of alloy 1100 with higher strength. it's a medium strength alloy that's hardenable only by cold work and isn't heat treatable. it's good weldability, formability and corrosion resistance.

Typical applications include general sheet work requiring greater strength than is provided by 1000 series aluminum alloys, profiled building sheet (roofing and siding), insulation panels, food and chemical handling equipment.

3003 aluminum specifications

Thickness (inch) Yield Strength Min. (ksi) Tensile Strength (ksi) Elongation (%)
Min.		 Bend Diameter Factor,N
Min. Max.
0.006 – 0.019 5.0 14.0 19.0 14 0
0.008 – 0.012 5.0 14.0 19.0 18 0
0.013 – 0.031 5.0 14.0 19.0 20 0
0.032 – 0.050 5.0 14.0 19.0 23 0
0.051 – 0.249 5.0 14.0 19.0 25 0
0.250 – 3.00 5.0 14.0 19.0 23 -
Thickness (inch) Yield Strength Min. (ksi) Tensile Strength (ksi) Elongation (%)
Min.		 Bend Diameter Factor,N
Min. Max.
0.017 – 0.019 12.0 17.0 23.0 3 0
0.020 – 0.031 12.0 17.0 23.0 4 0
0.032 – 0.050 12.0 17.0 23.0 5 0
0.051 – 0.113 12.0 17.0 23.0 6 0
0.114 – 0.161 12.0 17.0 23.0 7 0
0.162 - 0.249 12.0 17.0 23.0 8 0
0.250 – 0.499 12.0 17.0 23.0 9 -
0.500 – 2.000 12.0 17.0 23.0 10 -
Thickness (inch) Yield Strength Min. (ksi) Tensile Strength (ksi) Elongation (%)
Min.		 Bend Diameter Factor,N
Min. Max.
0.009 – 0.012 17.0 20.0 26.0 1 0
0.013 – 0.019 17.0 20.0 26.0 2 0
0.020 – 0.031 17.0 20.0 26.0 3 0
0.032 – 0.050 17.0 20.0 26.0 4 0
0.051 – 0.113 17.0 20.0 26.0 5 0
0.114 – 0.161 17.0 20.0 26.0 6 2
0.162 – 0.249 17.0 20.0 26.0 7 2
0.250 – 0.499 17.0 20.0 26.0 8 -
0.500 – 1.000 17.0 20.0 26.0 10 -
3003 aluminum properties
Property 3003 Data
Density, lb/in3 0.099
Modulus of Elasticity, psi 10.0 x 106
Coefficient of Thermal Expansion, 68-212˚F, /˚F 12.9 x 10-6
Thermal Conductivity, Btu/ft hr ˚F 112
Specific Heat, Btu/lb ˚F 0.213
Electrical Resistivity, Microohm-in 1.374

0.032inch 3003 Aluminum Alloy Metal Sheet Strip0.032inch 3003 Aluminum Alloy Metal Sheet Strip

Packaging & Delivery

  1. 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High),20-25 Metric ton
  2. 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High),20-25 Metric ton
  3. 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High),20-25 Metric ton
  4. export standard package,waterproof , moisture resistant
Q Introduce our company :
AShandong zhongcansteel new material co.,ltd. is located in Taian city,shandong province,if you are interested,welcome to visit our fatory.
Q Size we can do:
A Cold rolled steel coil: 0.12-2.0mm*Width*Coil
Cold rolled steel sheet: 0.12-2.0mm*Width*Length
Q We can send you samples before order:
A Yes, we can send you samples for free,And we are confident you like it.
Q Delivery terms :
A EXW, FOB (Qingdao or Xingang) or CIF your discharge port.
Q Delivery time?
A Color steel coil/ sheet: usually about 30 days and for some sizes,about 30days.
