Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Aisi And Astm Type 347 Stainless Steel Sheet Coil
Specifications
Brand Name :
DZSICO
Model Number :
347 347H
Certification :
SGS | ISO | CE | BV
Place of Origin :
CHINA
MOQ :
3000 Kilograms
Price :
$1.85 / Kilogram
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2000 Ton/tons Per Month 347 Stainless Steel Sheet Coils - Aisi And Astm
Delivery Time :
1-10T - 7Days, 11-25T - 10Days, 26-100 - 10Days, > 100-To be negotiated
Packaging Details :
Standard Seaworthy Package Or As Customers Requirement
Grade :
300 Series
Standard :
JIS, AiSi, ASTM, GB, DIN, EN
Length :
1000-6000mm
Width :
8-3000mm
Type :
347 stainless steel Plate
Application :
Industry, Construction
Surface :
BA / 2B / NO.1 / NO.3 / NO.4 / 8K / HL / 2D / 1D
Technique :
Cold Rolled or Hot Rolled
Stock or not :
Enough Stock
Description

Aisi And Astm Type 347 Stainless Steel Sheet Coil

347 stainless steel properties

347 stainless steel is a columbium/tantalum stabilized austenitic chromium-nickel stainless steel. This material is stabilized against chromium carbide formation by the addition of columbium and tantalum. Since these elements have a stronger affinity for carbon than chromium, columbium-tantalum carbides precipitate within the grains instead of forming at the grain boundaries. 347 should be considered for applications requiring intermittent heating between 800ºF (427ºC) and 1650ºF (899ºC) or for welding under conditions which prevent a post-weld anneal. 347 is non-magnetic.

347 stainless steel properties

*ASTM A 276 *UNS S34700
*ASTM A193 *AMS 5512
*ASME SA 269 *AMS 5646
*ASME SA 276 *ASTM A 269

347 stainless steel Chemical Composition
Element Percent by Weight
C Carbon 0.080%
Mn Manganese 200.00%
P Phosphorus 4.50%
S Sulfur 0.03
Si Silicon

75.00%
Cr Chromium 17.00-19.00
Ni Nickel 9.00-12.00
Nb Columbium and 10xC min to 1.00 max
Ta Tantalum
N Nitrogen 10.00%
Fe Iron

Balance

347 stainless steel Physical Properties

Grade Density Modulus of Elasticity in Tension Melting Range
g/cm3 lb/in3
321 7.92 0.286 28 x 106 psi
193 GPa		 1398-1446°C
2550-2635°F
347 7.96 0.288 28 x 106 psi
193 GPa		 1398-1446°C
2550-2635°F

Mean Coefficient of Linear Thermal Expansion

Temperature Range Coefficients
°C °F cm/cm/°C in/in/°F
20-100 68-212 16.6 x 10-6 9.2 x 10-6
20-600 68-912 18.9 x 10-6 10.5 x 10-6
20-1000 68-1832 20.5 x 10-6 11.4 x 10-6

347 stainless steel Thermal Conductivity
Temperature Range W/m·K Btu · in / hr · ft2 · °F
°C °F
20-100 68-212 16.3 112.5
20-500 68-932 21.4 147.7

347 stainless steel Specific Heat
Temperature Range J/kg K Btu/lb · °F
°C °F
0-100 32-212 500 0.12

Magnetic Permeability

  • H/m Annealed

  • 1.02 Max

347 stainless steel Electrical Resistivity
Temperature Range microhm·cm
°C °F
20 68 72
100 213 78
200 392 86
400 752 100
600 1112 111
800 1472 121
900 1652 126
347 stainless steel Mechanical Properties and Yield Strength
Property Type 321 Type 347
Yield Strength, 0.2% Offset
psi
MPa		 30,000
205		 30,000
205
Ultimate Tensile Strength,
psi
MPa		 75,000
515		 75,000
515
Percent Elongation in 2 in. or 51 mm 40.0 40.0
Hardness, Max.,
Brinell (Plate)
RB (Sheet & Strip)		 217
95		 201
92

347 stainless steel Common Applications

Aircraft collector rings
Aircraft exhaust stacks
Boiler casings
Cabin heaters
Furnace heating elements
Heavy wall welded equipment

Aisi And Astm Type 347 Stainless Steel Sheet CoilAisi And Astm Type 347 Stainless Steel Sheet Coil

# Product Transportation
The steel strips supplied according to the standard are usually applied with common rustproof oil film, which can be swept away with alkali solution. The supplier guarantees that the oiled products will be free from rust under normal packing, transportation, loading and storage conditions within 6 Months, the approved delivery date. However, product without oil coating can also be subject subject to statement in the contract reached after discussion between the user and the supplier.

Aisi And Astm Type 347 Stainless Steel Sheet Coil

Why Choose Us

1, Advantages

OEM customized fabrication service

Complete sizes,grade and MOQ

Full of inventory with large warehose

24 hours online service, feedback within one hour.

2, Products
variety standard:ASTM,DIN,JIS,BS,GB/T etc.
Large inventory.


3, Services
Quotations can be sent in 30 minutes.
Professional representative team 24 hours online service.
