SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
SCH5 Astm A671 Electric Fusion Welded Pipe Efw
Specifications
Brand Name :
DZSICO
Model Number :
ASTM A671
Certification :
ISO 9001:2008, SGS
Place of Origin :
CHINA
MOQ :
5 Tons
Price :
$500.00 - $800.00 / Ton
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Ton / Tons Per Month ASTM A671 Low CS Carbon Steel Pipes
Delivery Time :
25 Days
Packaging Details :
Seaworthy Standard Package
Standard Specification :
ASTM A671, ASME SA 671
Codes and Standards :
ANSI, ASME, ASTM, API, SAE, BS, AGA, AWWA, ISO, DIN
Dimensions :
ASME/ ANSI B36.10 / 19
Standard Size :
1/2” NB to 36” NB (EFW)
Wall Thickness :
3 - 12mm
Pipe schedules :
SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Producing techniques :
EFW / ERW / Welded / Fabricated
Available Shapes :
Round, Half Round, Square, Rectangular or Custom shape
Length :
3 to Max18 Meters or custom
Pipe End :
Beveled End, Plain End, Treaded
Test Certificate :
EN 10204 3.1 B
Tolerance :
± 5%
Description

ASTM A671 Electric CS Fusion Welded Carbon Steel Material EFW Pipes Manufacturers Price For Sale

# ASTM A671 Carbon Steel EFW Pipes General Information

Carbon Steel ASTM A671 EFW Straight Welded pipe is designed to be used in those applications, where the temperature ranges between ambience to low temperatures. This carbon steel specified ASTM A671 Pipe has been fabricated from a plate that is of a pressure vessel quality. A reason why our clients prefer using this carbon based steel A671 Welded pipe is due to its low cost in comparison to other stainless steel grade. The low cost of the A671 Electric Fusion Welded Pipe is because it has only two elements as the primary alloyants i.e. – carbon and iron. Therefore the cost of the A671 Grade EFW Pipe automatically becomes less unlike the other stainless steel grades which are alloyed with multiple metals like molybdenum, chromium and nickel, two of which are commodity traded metals. Thus, the prices tend to vary in comparison to these carbon based ASTM A671 Gr EFW Pipes.

Even though the cost of the carbon based ASTM a671 pipe grades is low, the metal still offers quite a few reasonable properties. For instance, the A671 Pipe has excellent tensile strength and ductility properties. Because the alloy used in the manufacture of A671 EFW pipes has better weldability and greater toughness properties, they can be used in applications which requires welding with low corrosion resistance properties. Apart from having a high tensile strength, this A671 Material is known to have a low thermal conductivity. We are one of the leading a671 pipe manufacturers, suppliers and exporter of these carbon specified pipes. At our factory, we conduct several tests such as tension test and transverse guided weld bend test, in order to check if these carbon steel pipes meet and conform to the mechanical properties of the ASTM a671 specification.

# ASTM A671 Carbon Steel EFW Pipes Standard Stock Specifications

► ASTM A671 Pipe ► ASTM A671 efw pipes ► Low CS A671 Pipe Material

► ASTM A671 Electric Fusion Welded Pipe ► ASTM A671 CS Atmospheric Temp Pipe

► ASTM A671 Grade Low Temp Pipe

# ASTM A671 Carbon Steel EFW Pipes Grades and Classes

Grades Material ASTM Spec
No. Grades and Classes
CA55 plain carbon A285/A285M Gr C
CB60 carbon steel (plain / killed) A515/A515M Gr 60
CB65 carbon steel (plain / killed) A515/A515M Gr 65
CB70 carbon steel (plain / killed) A515/A515M Gr 70
CC60 carbon steel (plain / killed), fine grain A516/A516M Gr 60
CC65 carbon steel (plain / killed), fine grain A516/A516M Gr 65
CC70 carbon steel (plain / killed), fine grain A516/A516M Gr 70
CD70 manganese-silicon, normalized A537/A537M Cl 1
CD80 manganese-silicon, quenched and tempered A537/A537M Cl 2
CK 75 carbon-manganese-silicon A299/A299M Gr A
CP 85 alloy steel, quenched, age hardening, precipitation heat treated A736/A736M Gr A, Class 3
CFA 65 nickel steel A203/A203M Gr A
CFB 70 nickel steel A203/A203M Gr B
CFD 65 nickel steel A203/A203M Gr D
CFE 70 nickel steel A203/A203M Gr E
CG 100 9% nickel A353/A353M
CH 115 9% nickel A553/A553M Type 1
CJA 115 alloy steel (AS), quenched and tempered A517/A517M Gr A
CJB 115 alloy steel (AS), quenched and tempered A517/A517M Gr B
CJE 115 alloy steel (AS), quenched and tempered A517/A517M Gr E
CJF 115 alloy steel (AS), quenched and tempered A517/A517M Gr F
CJH 115 alloy steel (AS), quenched and tempered A517/A517M Gr H
CJP 115 alloy steel (AS), quenched and tempered A517/A517M Gr P

# ASTM A671 Carbon Steel EFW Pipes Material Stock used for atmospheric and lower temperatures

ASTM A671 Low Temp Pipes EFW Black A671 CS Pipes
ASTM A671 Grade Welded Pipes Low CS ASTM A671 Oval Pipes
ASTM A671 Gr Erw Pipes A671 Grade CS Casing Pipe
Carbon Steel ASTM A671 Schedule 40 Pipes ASME B36.19 Low Carbon Steel ASTM A671 Grade Pipes
A671 CS Schedule 10 Pipes A671 Double Wall Pipes
Low CS ASTM A671 Efw Pipes Epoxy lined ASTM A671 Grade Pipes
A671 Grade CS Round Pipes PTFE lined A671 Grade CS Natural Gas Pipes
Low Carbon Steel ASTM A671 Grade Drill Pipes Carbon Steel ASTM A671 Grooved Pipes

# ASTM A671 Carbon Steel EFW Pipes grade wise Chemical Compatibility

A671 Grade Chemical composition
C Si Mn P S Ti
-/A45 -/0.17 - 0.98 0.035 0.035 -
-/A50 -/0.22 -
CA55 / A55 0.28 -
-/B55 -/0.20 0.13
~0.45
CB60 / B60 0.24
CB65 / B65 0.28
CB70 / C70 0.31 1.30
-/C55 -/0.18 0.55
~0.98
CC60/ C60 0.21
CC65 / C65 0.24 0.79
~1.30
CC70 / C70 0.27

# Low CS ASTM A671 Pipe Mechanical Properties Tensile Strength

Grades Yield Strength (N/mm2) Tensile Properties (N/mm2) Elongation (%) Welding point tensile strength (N/mm2)
-/A45 -/165 -/310~450 -/30 -/310~450
-/A50 -/185 -/345~485 -/28 -/345~485
CA55 / A55 205 380~515 27 380~515
-/B55 -/205 -/380~515 -/27 -/380~515
CB60 / B60 220 415~550 25 415~550
CB65 / B65 240 450~585 23 450~585
CB70 / C70 260 485~620 21 485~620
-/C55 -/205 -/380~515 -/27 -/380~515
CC60/ C60 220 415~550 25 415~550
CC65 / C65 240 450~585 23 450~585
CC70 / C70 260 485~620 21 485~620

SCH5 Astm A671 Electric Fusion Welded Pipe Efw

SCH5 Astm A671 Electric Fusion Welded Pipe Efw

1) Small diameter: Weight >Measurement
a. Length: ≤5.8m, loaded in 20FT Container, Max 27-28tons
b. Length: ≤11.8m, loaded in 40 FT Container, Max 27-28tons
c. Length: ≥12m, shipped by bulk vessel. FILO terms
2) Big dimater: Weight a. Size of

20 FT Container(inside :5898*2352*2350mm)

40 FT Container(inside: 12024*2352*2395mm)

Delivery time: Normal size: 7days send from warehouse directly.
Speial size: 25-30days custom made for you.

FAQ

1. How can I get a quotation from you ?

You can leave us message, and we will reply every message in time. Or we may talk on line by Trademanager.
And you can also find our contact information on contact page.
2.Can I get samples before order ?
Yes, of course. Usually our samples are free. we can produce by your samples or technical drawings. We can build the molds andfixtures.
3. what is your delivery time ?
The time of delivery is usually around 1 month(1*40FT as usual).
We can send out in 2 days, if it has stock.
4.What is your payment terms?
Our usual payment term is 30% deposite, and rest against B/L. L/C is also acceptatble.EXW,FOB,CFR,CIF,DDU.
5. How can you garantee what I got will be good ?
We are factory with 100% predelivery inspection which garantee the quality.
And as golden supplier on Alibaba. Alibaba assurance will make garantee,which means alibaba will pay your money back in advance if there is any problem with the products.
6 How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,?
no matter where they come from.
