12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
Specifications
Brand Name :
SPEZILLA
Model Number :
TP304 TP304L TP316L TP321 etc.
Certification :
ISO9001:2008, PED 97/23/EC
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T or L/C
Supply Ability :
1000 TONS / MONTH
Delivery Time :
10 DAYS
Packaging Details :
PLY-WOODEN CASE / BUNDLE WITH PLASTIC CAP
Product Name :
Welded Stainelss Steel Pipe
Shape :
Round
Pipe Spec. :
ASTM A312/A358
Materials :
TP304, TP304L, TP316L, TP321 etc.
O.D. :
1/2'' - 24''
W.T. :
SCH5S - 80S
Length MAX :
12000MM Max.
Pipe Finish :
ANNEALED & PICKLED
Package :
Wooden Case/Bunlde
Application :
Industry
Description

12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe

Descriptions:

ASTM A-778 Welded Stainless Steel Pipe

Grades: 304L and 316L


Sizes:

3” - 36” Sch5S and Sch10S


6” - 12” NPS Gauge Pipe

ASTM A-312 Welded Stainless Steel Pipe


Grades: 304/304L and 316/316L Dual Certified


Sizes:

2” - 24” Sch5S, Sch10S and Sch40S


8” - 12” .250 nominal (Sch20)


14” - 20” .250 nominal (Sch10)


2” - 12” Sch10S (minimum wall)


2” - 8” Sch40S (minimum wall)


Specifications:

Trade Name
Grade
UNS #
Welded Pipe
(without Filler Metal)
Welded Pipe
(with Filler Metal)
304
TP304
S30400
A312 / SA312
A358 / SA358
304L
TP304L
S30403
A312 / SA312
A358 / SA358
304H
TP304H
S30409
A312 / SA312
A358 / SA358
316
TP316
S31600
A312 / SA312
A358 / SA358
316L
TP316L
S31603
A312 / SA312
A358 / SA358
316H
TP316H
S31609
A312 / SA312
A358 / SA358
321
TP321
S32100
A312 / SA312
A358 / SA358
321H
TP321H
S32109
A312 / SA312
A358 / SA358
347
TP347
S34700
A312 / SA312
A358 / SA358
347H
TP347H
S34709
A312 / SA312
A358 / SA358
317L
TP317L
S31703
A312 / SA312
A358 / SA358

Welded Stainless Steel Pipe Tolerances:

NPS Designator Permissible Variations in Outside Diameter
Over In. Under In.
1/8 to 1-1/2, incl 1/64 (0.015) 1/32 (0.031)
Over 1-1/2 to 4, incl 1/32 (0.031) 1/32 (0.031)
Over 4 to 8, incl 1/16 (0.062) 1/32 (0.031)
Over 8 to 18, incl 3/23 (0.093) 1/32 (0.031)

Nominal Wall Thickness:

NPS Designator

Outside Diameter in.

Schedule 5S in.

Schedule 10S in.

Schedule 40S in.

Schedule 80S in.
1/4 0.540 0.065 0.088 0.119
3/8 0.675 0.065 0.091 0.126
1/2 0.840 0.065 0.083 0.109 0.147
3/4 1.050 0.065 0.083 0.113 0.154
1.0 1.315 0.065 0.109 0.133 0.179
1 1/4 1.660 0.065 0.109 0.140 0.191
1 1/2 1.900 0.065 0.109 0.145 0.200
2 2.375 0.065 0.109 0.154 0.218
2 1/2 2.875 0.083 0.120 0.203 0.276
3 3.500 0.083 0.120 0.216 0.300
3 1/2 4.000 0.083 0.120 0.226 0.318
4 4.500 0.083 0.120 0.237 0.337
5 5.563 0.109 0.134 0.258 0.375
6 6.625 0.109 0.134 0.280 0.432
8 8.625 0.109 0.148 0.322 0.500
10 10.750 0.134 0.165 0.365 0.500
12 12.750 0.156 0.180 0.375 0.500

12000MM Length Schedule 40 Stainless Steel Pipe , Welding Thin welded steel pipe
