Specifications
Brand Name :
SPEZILLA
Model Number :
ASTM A270
Certification :
ISO9001:2008, PED 97/23/EC
Place of Origin :
CHINA
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T or L/C
Supply Ability :
1000 TONS / MONTH
Delivery Time :
10 DAYS
Packaging Details :
PLY-WOODEN CASE / BUNDLE WITH PLASTIC CAP
Product Name :
Stainless Steel Tube
Standard :
ASTM A270
Materials :
TP316/316L TP304/304L
O.D. :
1"
W.T. :
1.65mm
Length :
20ft
Pipe Finish :
320 grit inter & Outer Polished
Shape :
Round
Package :
Wooden Case
Application :
Food
Description

TP316 / 316L Polished 304 stainless Instrument Tubing 1"x0.065"x20ft Welded

SPEZILLA is leading manufacturer & suppliers of stainless steel seamless and welded tubing manufactured as per ASTM A270 standards. It is certified to the requirements of ASTM A270 standards, and most user specifications.Our customers have come to rely on the quality of Spezilla’s sanitary tube products as well as our uncompromised commitment to total customer satisfaction. We stock all sanitary tube sizes from ½” to 6.0” OD in 20 ft. standard lengths. Custom lengths and sizes are available upon request.

Available Sizes:


OD from 1/2'' to 8'' (12.7MM to 203.20MM)


Wall thickness: 0.065'' to 0.083'' (1.65MM to 2.11MM)

Length: 20ft ( 6100MM)

Surface Polish:

Surface finish is 20 u-in Ra (0.5um) ID maximum, 30 u-in Ra (0.8um) OD maximum surface roughness measured per ASME/ANSI B46.1 with the profilo-meter reading at 90 degree to the lay. Other finishes available upon request.

Size Range
Outside Diameter: 1/2" – 8"
Wall Thickness: .065" and .083"

Governing Production Specifications - ASTM A270/A269/A249

Outside Diameter (O.D.) Dimensional Tolerances
Over Under
1.000" and Smaller 0.005" 0.005"
Over 1" to 2" 0.008" 0.008"
Over 2" to 3" 0.010" 0.010"
Over 4" to < 5½", excl 0.015" 0.015"
5½" to 8", excl 0.030" 0.030"
8" to 12" 0.050" 0.050"

Grades TP 304 TP 304L TP 316 TP 316L
C max 0.07 0.03 0.08 0.03
Mn max 2.00 2.00 2.00 2.00
P max 0.045 0.045 0.045 0.045
S max 0.03 0.03 0.03 0.03
Si max 0.75 0.75 0.75 0.75
Cr 17.5 -- 19.5 17.5 -- 19.5 16 -- 18 16 -- 18
Ni 8 -- 10.5 8 -- 12 10 -- 14 10 -- 14
N max 0.10 0.10 0.10 0.10
Mo -- -- 2.00-3.00 2.00-3.00

erial ASTM A270 Chemical Composition % Max
C Mn P S Si Cr Ni Mo N B Nb Ti
TP304 0.08 2.00 0.045 0.030 1.00 18.0-20.0 8.0-11.0 ^ ^ ^ . ^
TP304L 0.035 2.00 0.045 0.030 1.00 18.0-20.0 8.0-12.0 ^ ^ ^ ^
TP316 0.08 2.00 0.045 0.030 1.00 16.0-18.0 10.0-14.0 2.00-3.00 ^ ^ ^
TP316L 0.035 D 2.00 0.045 0.030 1.00 16.0-18.0 10.0-15.0 2.00-3.00 ^ ^ ^
TP321 0.08 2.00 0.045 0.030 1.00 17.0-19.0 9.0-12.0 ^ ^ ^ 5C -0.70
TP347 0.08 2.00 0.045 0.030 1.00 17.0-19.0 9.0-12.0 10C -1.10 ^

Size

(TUBE O.D.)

 GAUGE WALL LBS/FT

STOCK

304

STOCK

316L
1/2 16 .065 .3020 Y Y
3/4 16 .065 .4755 Y Y
1 18 .049 .4980 Y Y
1 16 .065 .6490 Y Y
1-1/2 18 .049 .7593 Y Y
1-1/2 16 .065 .9962 Y Y
2 18 .049 1.0210 Y Y
2 16 .065 1.3430 Y Y
2 1/2 16 .065 1.6900 Y Y
3 16 .065 2.0370 Y Y
4 14 .083 3.4720 Y Y
6 12 .109 6.9000 Y Y
8 12 .109 9.3000 Y Y

ASME BPE Stainless Steel Sanitary Tubing Surface Finish
Mechanically Polished Ra Max.
Surface Designation u-inch um
SF1 20 0.51
SF2 25 0.64
SF3 30 0.76
Mechanically Polished & Electrpolished
SF4 15 0.38
SF5 20 0.51
SF6 25 0.64

TP316 / 316L Polished 304 stainless Instrument Tubing 1
