Specifications
Brand Name :
DELTA
Model Number :
Monel k500
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Sheet & Plate
Grade :
Monel k500
Thickness :
0.6 - 20.0mm
Standard size :
1000*2000mm 1219*2438mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1 NO.4 NO.8
Description

Nickel Alloy K500 Thickness 0.4 - 30.0mm Monel K500 Sheet & Plate ASTM EN JIS Standard

Products Name Monel K-500 Nickel Alloy Sheet & Plate
Thickness Cold rolled: 0.6 - 3.0mm Hot rolled 4.0 - 30.0mm
Standard Size 1000*2000mm 1219*2438mm 1219*3048mm 1500*6000mm
Surface 2B NO.1
MOQ 50 kgs
Service Laser Cutting, Surface Finishing
Packing Waterproof paper and wooden pallets
Loading Port Shanghai Port
Price term FOB CFR CIF EXW
Payment term 30% TT in advance , 70% TT balance against copy of B/L
Other Grade Hastelloy C22 C4 X
Monel 400 K500
Incoloy 800 800H 800HT 825 925
Inconel 600 601 625 716 718
Stainless Steel Grade 201 202 301 304L 309S 310S 316L 316Ti 317L 321 347 409L 410 410S 420J1 420J2 430 431 436L 439 440A/B/C 441 443 444 2205 2507 904L 254SMO 253MA

What is Monel Alloy K500 Sheet & Plate

Rexton steel & alloys are the leading manufacturers, supplier, and exporter of the appreciable quality of Monel K500 Sheet & Plate. No doubt the offered product to the buyers is fabricates using stunning quality of Monel alloy. The product is provided to global and domestic buyers at wider range exactly as per the demand they have made from the supplier. To meet all the desires of the buyers the industry is offering the sheet & plates in different specifications that vary in standards, sizes, type, finishes, length etc. Today this product because of goodness in its quality is found to be used at various applications in industries.

How are the sheet & plate produced?


Every manufacturing industry is taking full care of the production of Monel K500 Sheet & Plate so that excellent quality of the product can be produced. The fabrication of the ordered consignment is done by effectively using high quality of Monel alloy. The alloy is bought from the best mills and is well tested before used for making sheet & plate. Manufacturing of the sheet and plate is done in national and international quality standards.

onel Alloy K500 Hot Rolled (HR) Sheet & Plates, ASME SB 127 Monel K500 Sheet, Monel K500 Plates Stockists in Mumbai, Monel K500 Cold Rolled (CR) Sheet & Plate, Monel K500 Sheet and Plate Supplier in China

The quality control team and professional experts are assuring in helping the manufacturer in making an excellent quality of sheet & plate. In the manufacturing industry, the effectiveness in production is also assured by using available modern and advanced technology and high quality of machinery.

What all qualities do it has?


There are many good qualities one will find the product to have in it. No doubt this has become possible due to the proper use of top-notch quality of Monel alloy and guidance of professional experts. It includes high tensile strength, good dimensional accuracy, rugged construction, fine surface finishes, durability, flexibility, longevity. It is having greater ability to be fully general corrosion resistance, pitting, oxidation, stress corrosion cracking, crevice corrosion resistance. Thus, today it is found used in different applications that desire it to have.

Testing-


The material testing has become an important part of the entire production of Monel K500 Sheet & Plate. The testing needs to be necessarily conducted in order to make sure that no poor quality of the product is supplied to the product. The test conducted is positive material identification test, pitting resistance test, hardness test, and intergranular corrosion test. Also the other test testing like flattening test, mechanical test, flaring test, chemical test, macro test, and micro test.

ASTM B127 Monel K500 Sheet & Plate Exporter, Monel K500 Circles, Monel Alloy K500 Shim Sheets, Monel K500 Coils, Monel K500 Perforated Sheets Supplier in Mumbai, Monel K500 Export Quality Sheet & Plate Stockists

Destructive and Non-Destructive Testing

  • Mechanical examining like tensile, Elongation
    and reduction of area.
  • Chemical examination
  • Radiographic Test
  • Pitting Corrosion Test
  • Positive material recognition
  • Eddy Current test
  • Buckling & Crushing test

Monel K500 Sheet & Plate Processing

  • Hot rolled
  • Cold rolled
  • Cutting
  • Forming Drilling/ Machining
  • Grinding
  • Polishing
  • Testing

Monel K500 Sheet & Plates Equivalent Grades :

STANDARD WERKSTOFF NR. UNS
Monel K500 2.4375 N05500

Chemical Composition of Monel Alloy K500 Sheet & Plate

Grade C Mn Si S Cu Fe Ni
Monel K500 0.30 max 2.00 max 0.50 max 0.024 max 28 – 34 2.50 max 63.00 min

Mechanical Properties of Monel K500 Sheet & Plates

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.8 g/cm3 1350 °C (2460 °F) Psi – 80,000 , MPa – 550 Psi – 35,000 , MPa – 240 40 %
