ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
Specifications
Brand Name :
BAOSTEEL TISCO
Model Number :
201 202 301 304 316L 321 309S 310S 317L 329 347 2205 .etc
Certification :
ISO
Place of Origin :
China
MOQ :
1 Ton
Price :
1200 -2000 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Stainless Steel Sheet
Grade :
200 series 300 series 400 series
Thickness :
0.3 - 3.0mm
Tech :
cold rolled
Width :
1000mm 1219mm 1500mm or customs as request
Surface :
2B BA NO.1 NO.4 8K HL Color finishing
Standard :
ASTM GB JIS EN DIN
MOQ :
1 Ton
Description

ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm

Product Information

Alloy 405 is a 12% chromium stainless steel designed to be used in the as-welded condition. Unlike the other grades of 12% chromium stainless, 405 is not vulnerable to extensive hardening through air cooling from high temperatures.


Stainless Steel 405 Plates Specifications:

Specifications ASTM A240, ASME SA240
Standard JIS, ASTM, AISI, GB, EN, DIN
Surface 2B, 2D, BA, NO.4, NO.8, 8K, Mirror, Checkered, Embossed, Hair Line, Sand Blast, Brush, Etching
Finish Cold rolled, Hot rolled
Width 1000-2000mm
Length 1000-6000mm
Thickness 0.40mm – 6.00mm
Technical data
Grade Specifications for Stainless Steel 405 Sheets
STANDARD WERKSTOFF NR. UNS JIS AFNOR
SS 301 1.4002 S40500 SUS 405 Z4 CA 13

Chemical Properties of SS 405 Sheets

ELEMENT C Mn P S Si Cr Al Fe
SS 405 0.080 max 1.00 max 0.040 max 0.030 max 1.00 13.00 0.2 85

Mechanical Properties of SS 405 Sheets
Grade/Temper Tensile Strength

ksi (min.)

 Yield Strength 0.2%

ksi (min.)

 Elongation -% in 50 mm (min.)
SS 405 448 MPa 276 MPa 25.00%

S 405 Plate Equivalent grades
JIS G4304 ASTM UNS KS EN10095 AS CNS
SUS405 405 S40500 STS405 1.4002 405 405

Applications that frequently use alloy 405 include, but are not limited to:

  • Steam nozzles
  • Partitions
  • Annealing boxes
  • Quenching racks
  • Fabrications that cannot be annealed after welding

ASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mmASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mmASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mmASTM A240 405 Stainless Steel Sheet 1.4002 / 04Cr13 Stainless Steel Sheet SS Sheet 0.3 - 2.5mm
