Specifications
Brand Name :
TISCO
Model Number :
409L
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
1410-1620USD/Ton
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Stainless Steel Sheet
Grade :
Stainless Steel 409L
Standard :
ASTM EN JIS GB
Size :
1219*2438mm
Thickness :
0.5 - 3.0mm
Type :
cold rolled
Service :
cutting, surface treatment
application :
auto exhaust pipe
Packing :
wooden pallets
Description

409L SS Sheet / 409L Stainless Steel Plate ASTM A240 Standard Thickness 0.4 - 3.0mm

Products Specification

Products Name 409L Stainless Steel Sheet
Standard ASTM EN JIS GB BIS
Thickness 0.4mm 0.5mm 0.6mm 0.8mm 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm
Surface 2B 2D or process other surface as request
Standard Size 1219*2438mm 1000*2000mm
Service Slit Cutting, bending , surface treatment
Other Grade 200 Series: 201 202
300 Series: 301 304 304L 309S 310S 316L 316Ti 317l 321 329 347
400 Series: 409L 410S 416 420 431 436L 439 441 443 444 446
Special Grade: 254SMO 904L 2205 2507 253MA Nickel Alloy
MOQ 500 kgs
Packing Wooden Pallets and waterproof paper

Introduction

Grade 409 stainless steel is a Ferritic steel that offers good mechanical properties and high-temperature corrosion resistance. It is commonly considered as a chromium stainless steel, with applications in exhaust systems of automobiles and applications that demand weldability.

Grade 409 steels are also available in highly stabilized forms, such as grades S40930, S40920 and S40910. The stability of these grades is provided by the presence of niobium, titanium, or both, in the composition of steels.

Key Properties

The properties given below relate to annealed tubing of ASTM A268. The specified properties may not be similar to other products such as bar and coil.

Composition

The typical chemical compositional ranges of grade 409 stainless steels are given below:

Table 1 - Composition ranges of grade 409 stainless steels

Grade C Mn Si P S Cr Ni Ti
409

min.

max.

-

0.08

-

1.00

-

1.00

-

0.045

-

0.045

10.5

11.75

-

0.5

6x C

0.75

Mechanical Properties

The table below provides the mechanical properties of grade 409 stainless steels:

Table 2 - Mechanical properties of grade 409 stainless steels

Grade Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
409 450 240 25 75 131


Physical Properties

The physical properties of annealed grade 409 stainless steels are tabulated below:

Table 3 - Physical properties of annealed grade 409 stainless steels

Grade Density (kg/m3) Elastic Modulus (GPa) Mean Coefficient of Thermal Expansion (μm/m/°C) Thermal Conductivity (W/m.K) Specific Heat 0-100°C (J/kg.K) Electrical Resistivity (nΩ.m)
0-100°C 0-315°C 0-538°C at 100°C at 500°C
409 7800 200 11.0 11.7 12.4 25.8 27.5 460 600

Grade Specification Comparison

Table 4 provides approximate grade comparisons of 409 stainless steels:

Table 4 - Grade specifications for 409 grade stainless steel

Grade UNS No Old British Euronorm Swedish SS Japanese JIS
BS En No Name
409 S40900 409S19 - 1.4512 X6CrTi12 - SUH 409

Heat Resistance

Grade 409 stainless steels offer scaling resistance at temperatures up to 675°C during continuous operation, and up to 815°C under intermittent conditions. These temperatures pertain to specific service environments.

Heat Treatment

Annealing of grade 409 steels is carried out at temperatures ranging from 790 to 900°C, followed by air-cooling. Thermal treatment does not harden grade 409 steels.

Welding

Grade 409 steels must be pre-heated to temperatures of 150 to 260°C before welding. Although grade 430 and 409 filler rods or electrodes can be used during welding of grade 409 steels, grade 309 electrodes or filler rods are strongly recommended by AS 1554.6. Care should be taken to weld grade 409 steels with minimum heat, in order to mitigate grain growth.

Ductility of the welded products can be improved by annealing post-welding at temperatures of 760 to 815°C. However, this is not required for thin welded products. Welding of exhaust tubing of automobiles is carried out without filler rods.

Applications

The typical applications of grade 409 stainless steels are listed below:

  • Automotive exhaust tubing
  • Catalytic converter systems
  • Mufflers
