Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil
Specifications
Brand Name :
TISCO
Model Number :
430 / 1.4016 /SUS430
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
1410 - 1620 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
stainless steel strip
Thickness :
0.1-2.0mm
Width :
within 1219mm
MOQ :
400 KGS
Grade :
200 series 300 series 300 series
Surface :
BA 2B NO.4 HL 8K NO.1 2D
Standard :
ASTM EN GB JIS
Packing :
wooden frame and water proof paper
Description

Precision Stainless Steel Strip Grade AISI430 / SUS430 / EN 1.4016 SS Strip Coil

Specification Of Stainless Steel Strip
Product Name 430 Stainless Steel Strips
Material Stainless Steel
Standard ASTM JIS GB EN
Other Grade 201 202 301 304 304L 309S 310S 316L 317L 410 420 430 436L 441 2205 2507 904L C276
Thickness 0.05mm-3.0mm
Width 30mm-600mm
Finish No.1, No.2, Bright Annealed, TR, Polished, etc.
Edge Mill edge, Slit edge, Square edge, Round edge, etc.
Coating PE coating, Paper coating
Coil ID 508mm/610mm
Payment Terms T/T, L/C
Delivery Time As per quantity required

Introduce of 430 / SUS430 / EN 1.4016 Stainless Steel

SS 430 is a corrosion and heat resistant ferritic Chromium Steel. It can be polished to appear similar to Chromium plate. The material is magnetic in both annealed and cold rolled tempers.

The alloy can be readily blanked and formed. The material can be resistance welded, brazed, and soldered. SS 430 is resistant to atmospheric corrosion and fresh water, but it not resistant to most salts and sea water. It is resistant to scaling by oxidation up to about 1400°F.

Available Sizes:

SS 430 is available from our company as strip product in thicknesses from 0.05mm - 3.0mm in widths up to 1219mm. The material conforms to ASTM JIS GB EN Standard.

Nominal Composition of Our 430 Stainless Steel Strip

Grade C Mn Si Ni Cr Fe
430 0.05 0.51 0.38 0.14 16.25 Bal

Mechanical Properties of our 430 Stainless Steel Strip

SS 430 MECHANICAL PROPERTIES
ANNEALED COLD ROLLED
Ultimate Tensile Strength 75,000 PSI 145,000 PSI
Yield Strength (0.2% Offset) 45,000 PSI 135,000 PSI
Elongation in 2” * 30% 1%
Modulus of Elasticity (Tension) 29 x 106 PSI
Poisson’s Ratio 0.27

*The measured elongation will be less as thickness decreases to 0.002” and less.
These values may be adjusted by control of process variables – consult HPM for desired values

Physical Properties of 430 Stainless Steel Strips

Density 0.28 lbs/cu.in.
Melting Point (Approx.) 1425°C
Electrical Resistivity @ R.T. 60 Microhm·cm
Temperature Coefficient of Resistivity (TCR) (0° to 100°C) 10.5 x 10-6 /°C
Thermal Conductivity @ 100°C 26.1 W/m·K
Magnetic Permeability 800
Magnetic Attraction Yes

Packing and Delivery Informations

  • Standard export packaging:
    Waterproof Paper Winding + PVC Film + Strap Banding + Wooden Pallet or Wooden Case;
  • Customized packaging as your request (Logo or other contents accepted to be printed on the packaging);
  • Other special packaging will be designed as customer’s request;
  • Eye to wall and eye to sky are both available;
  • By International Express: DHL / UPS / FEDEX / EMS and our own express line;
  • By air or By sea;
  • Shipping port: Shanghai, Ningbo or as your request.
