Specifications
Brand Name :
BAOSTEEL BENSTEEL HBIS XINGCHENG
Model Number :
AR500
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
835 - 954USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Wear Resistant Steel Plate
Thickness :
4.0 - 40.0mm
Width :
1000-2200mm
Length :
2000-12000mm
Standard :
ASTM EN GB
Other Grade :
AR400 / AR450 / AR500 / AR600
Brand :
BAOSTEEL XINYU XINGCHENG HBIS
Service :
Cutting
Description

AR500 Steel Plate for High-Abrasion Applications AR500 Wear Plate / AR500 Abrasion Plate


Products Specification of Wear Resistant Steel Plate

Products Name Abrasion Resistant AR500 Steel Plate
Thickness 4.0 - 40.0mm
Width 100 - 2200mm custom cutting any size as request
Length 6m 8m 10m 11.5m 12m or cutting any length as request
Standard ASTM JIS GB EN
MOQ 500 Kgs
Deliver time 7 - 14 days
Loading Port Shanghai Port
Packing wooden pallets
Other Grade AR400 / AR450 / AR500 / AR600 NM400 NM450 NM500 NM600
Service Cutting, Heat treatment

AR500 ABRASION-RESISTANT STEEL

AR500 abrasion resistant steel plate offers high surface hardness for excessive wear and high-impact applications.

WHAT IS AR500 STEEL?

AR500 is a grade of abrasion resistant (AR) steel plate that is known for its hardness, toughness, and resistance to wear and tear. This grade has one of the highest levels of hardness out of the common AR steel plate grades - with a Brinell Hardness Number (BHN) of between 460-544 - and is typically used in high-wear and impact applications. AR500 steel plate meets ASTM E10 specifications for Brinell hardness testing.

Overview:

  • Abrasion resistant steel plate grade used in high-wear applications, such as in mining equipment and concrete handling.
  • Surface hardness can range between 470-540 BHN.
  • Possesses excellent resistance to slide wear, rub wear and heavy wear.
  • Can withstand high-impact stresses, even at extremely low temperatures.
  • Composition and hardening processes differ between mills. Mill test reports are supplied with each order.

Benefits of AR500 Steel

The hardness and toughness of AR500 steel plate make it extremely resistant to wear and impact. These properties make AR500 steel a durable, long-lasting material, which is crucial in applications that require materials that can withstand extreme wear.

The durability of AR500 also means that the material needs to be replaced less often than materials that have lower resistance to abrasion, which can lower material costs and prevent devastating equipment failures.

Available Sizes

Leeco® Steel stocks the following standard sizes of AR500 steel plate, but other sizes may be available for special orders.

THICKNESS WIDTH LENGTH
AR500 3/16" – 2" 48" – 96" UP TO 480"

What's the different between AR400 and AR500?

The major difference is impact resistance. AR500 has higher abrasion resistance, but AR400 has higher impact resistance. That sounds the same to me, but it isn’t. Let’s break it down with a real-world situation.

I work at a rock quarry, AR400 Steeland I’m looking to line different pieces of equipment with abrasion resistant steel plate. I have a fleet of dump trucks, and the bed of the trucks are usually lined with removable bed liners. The beds take a lot of impact when the rocks fall into the bed after being excavated, so I need something that will hold up and will be less likely to shatter from the falling rocks. I’m going to choose AR400 plate for this because AR400 is really good for projects with high impact compared to AR500. Since AR400 plate is softer than AR500 plate, it can withstand more impact without cracking or shattering.

Same quarry, same rocks, new piece of equipment. After we have the rocks in the bed of the truck, they need to go somewhere. The next step is dumping the rocks into a conveyor system to be sorted and then sized in a rock crusher. After the rocks leave the rock crusher, they slide into a chute. I have to update this chute liner, and I’m going to choose

AR500 steel because the rocks are just sliding down instead of being thrown or dropped onto it. AR500 steel can withstand the abrasion that the rocks cause by sliding better than the AR400 steel, meaning it would last longer.
