EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
Specifications
Brand Name :
DELTA
Model Number :
Hastelloy C276 / UNS N10276 / 2.4819
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel alloy bars
Grade :
Hastelloy C276
Diameter :
DN6-DN400
Length :
6000mm or custom cutting any length as request
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
Black, bright
Description

EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube

Type Nickel Alloy Tube/Pipe
Length 1000mm,3000mm, 5800mm, 6000mm,etc
Standard ASTM,AISI,JIS,DIN,EN
Application Construction,Ship,Boiler,Machinery,etc
Certification ISO,SGS,TUV
Technique Cold Rolled/Hot Rolled
Quality Mill Test Certificate supplied with the shipment ,third part inspection is acceptable



Grade		 Hastelloy: Hastelloy B/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g;etc
Inconel 600/601/602CA/617/625/713/718/738/X-750;ETC
Incoloy: Incoloy 800/800H/800HT/825/925/926;etc
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044,etc
Monel: Monel 400/K500/R405,etc
Nitronic 40/50/60/75/80A/90/A263 ;etc
Specification Wire: 0.02-6mm /Strip: 0.05*5.0-5.0*250mm /Bar: φ4-800mm;Length 2000-5000mm /Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm /Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm
Cutting Type Laser cutting;water-jet cutting;flame cutting
Protection 1. Inter paper available2. PVC protecting film available

Hastelloy C276 Seamless Pipe Chemical Composition

Alloy C276 Ni C Mo Mn Si Fe P S Co Cr
Balance 0.010 max 15.00 – 17.00 1.00 max 0.08 max 4.00 – 7.00 0.04 max 0.03 max 2.5 max 14.50 – 16.50

C276 Hastelloy Seamless Pipe Mechanical Strength Table

Density Melting Point Yield Strength (0.2%Offset) Tensile Strength Elongation
8.89 g/cm3 1370 °C (2500 °F) Psi – 52,000 , MPa – 355 Psi – 1,15,000 , MPa – 790 40 %

DIN/EN UNS No International name Component
1 2.406 N02000 Nickl200 99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.1C
2 2.4601 N02201 Nickl201 99Ni-0.15Fe-0.2Mn-0.1Si-0.1Cu-0.01C
3 2.405 N02270 Nickl270 99.9Ni-0.02Fe-0.001Mn-0.002Si-0.005Cu-0.01C
4 1.498 S66286 INCOLOY Alloy A286 25Ni-15Cr-1.5Mo-2Ti-1Mg-0.03C
5 N08367 INCOLOY Alloy 25-6HN 25Ni-20Cr-6.3MO-0.25Cu-0.2N-0.01P-0.05S-0.01C
6 1.4529 N08926 INCOLOY Alloy 25-6Mo 25Ni-20Cr-6.5Mo-1Cu-0.2N-1.0Mg-0.01P-0.005S-0.01C
7 2.446 N08020 INCOLOY Alloy 20 36Ni-21Cr-3.5Cu2.5Mo-1Mn-0.01C
8 1.4563 N08028 INCOLOY Alloy 28 32Ni-27Cr-3.5Mo-1Cu-0.01C
9 1.4886 N08330 INCOLOY Alloy 330 35Ni-18Cr-2Mg-1SI-0.03C
10 1.4876 N08800 INCOLOY Alloy 800 32Ni-21Cr-0.3~1.2(Al+Ti)0.02C
11 1.4876 N08810 INCOLOY Alloy 800H 32Ni-21Cr-0.3~1.2(Al+Ti)0.08C
12 2.4858 N08825 INCOLOY Alloy 825 42Ni-21Cr-3Mo-2Cu-0.8Ti-0.1AI-0.02C
13 2.4816 N06600 Inconel Alloy 600 72Ni-151Cr-8Fr-0.2Cu-0.02C
14 2.4851 N06601 Inconel Alloy 601 60Ni-22Cr-1.2Al-0.02C
15 2.4856 N06625 Inconel Alloy 625 58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C
16 2.4856 N06626 Inconel Alloy 625LCF 58Ni-21Cr-9Mo-3.5Nb-1CO-0.02C
17 2.4606 N06686 Inconel Alloy 686 57Ni-21Cr-16Mo-4W-0.01C
18 2.4642 N06690 Inconel Alloy 690 58Ni-30Cr-9Fe-0.2Cu-0.02C
19 2.4668 N07718 Inconel Alloy 718 52Ni-19Cr-5Nb-3Mo-1Ti-0.6Al-0.02C
20 2.4669 N07750 Inconel Alloy 750 70Ni-15Cr-6Fe-2.5Ti-0.06Al-1Nb-0.02C
21 2.436 N04400 MONEL400 63Ni-32Cu-1Fe-0.1C
22 2.4375 N05500 MONEL K-500 63Ni-30Cr-1Fe-3Al-0.6Ti-0.1C
23 2.4819 N10276 Hastelloy C-276 57Ni-16Mo-16Cr-5Fe-4W-2.5Co-1Mn-0.35V-0.08Si-0.01C
24 2.461 N06455 Hastelloy C-4 65Ni-16Cr-16Mo-0.7Ti-3Fe-2Co-1Mn-0.08Si-0.01C
25 2.4602 N06022 Hastelloy C-22 56Ni-22Cr-13Mo-3Fe-2.5Co-0.5Mn-0.35V-0.08Si-0.01C
26 2.4675 N06200 Hastelloy C-2000 59Ni-23Cr-16Mo-1.6Cu-0.08Si-0.01C
27 2.4665 N06002 Hastelloy X 47Ni-22Cr-18Fe-9Mo-1.5Co-0.6W-0.1C-1mn-1Si-0.008B
28 2.4617 N10665 Hastelloy B-2 69Ni-28Mo-0.5Cr-1.8Fe-3W-1.0Co-1.0Mn-0.01C
29 2.466 N10675 Hastelloy B-3 65Ni-28.5Mo-1.5Cr-1.5Fe-3W-3Co-3Mn-0.01C
30 N06030 Hastelloy G-30 43Ni-30Cr-15Fe-5.5Mo-2.5W-5Co-2Cu-1.5Mn-0.03C
31 N06035 Hastelloy G-35 58Ni-33Cr-8Mo-2Fe-0.6Si-0.3Cu-0.03C
32 1.4562 N08031 Nicrofer hMo31 31Ni-27Cr-6.5Mo-1.2Cu-2mn-0.01C
33 2.4605 N06059 Nicrofer hMo59 59Ni-23Cr-16Mo-1.0Fe-0.01C

FAQ

Q: Are you a manufacturer?
A: Yes , We are a metal manufacturer, We have own factory, which is located in JIANGSU,CHINA. We have a leading power in producing and exporting steel pipe,galvanized steel pipe,hollow section,galvanized hollow section, etc. We promise that we are what you are looking for.
Q:Can we visit your factory ?
A:Warmly welcome once we have your schedule we will pick you up .
Q: Do you have quality control?
A: Yes, we have gained BV, SGS authentication.
Q: Can you arrange the shipment?
A: Sure, we have permanent freight forwarder who can gain the best price from most ship company and offer professional service.
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 25-45 days if the goods are not in stock, it is according to quantity.
Q:How can we get the offer?
A: Please offer the specification of the product,such as material,size,shape,etc.So we can give the best offer.
Q:Can we get the some samples? Any charges?
A: Yes , we could offer the sample for free charge but do not pay the cost of freight . If you place the order after confirm the sample , we will refund your express freight or deduct it from the order amount.
Q: How do you make our business long-term and good relationship?
A: 1.We keep good quality and competitive price to ensure our customers' benefit.
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
EN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 TubeEN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 TubeEN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 TubeEN 2.4819 Nickel Alloy Seamless Pipe DN10 - DN300 Wall Thickness SCH40S Hastelloy C276 Tube
