Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
Specifications
Brand Name :
DELTA
Model Number :
Alloy 23MnNiMoCr54
Certification :
ISO
Place of Origin :
China
MOQ :
1 Ton
Price :
600-885USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products Name :
Alloy Steel Round Bar
Diameter :
10 - 350mm
Length :
6m
Tech :
Hot rolled
Service :
Cutting
MOQ :
1 Ton
Loading Port :
Shanghai Port
Standard :
ASTM EN GB
Description

Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter

Products Specification

Products Name

Alloy 23MnNiMoCr54 Steel Round Bar
Diameter 10 - 300mm
Length 6m or custom cutting any length as request
Type Hot Rolled
Brand BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc
MOQ 1 Ton
Loading Port Shanghai Port
Packing packing by steel wire rope
Deliver time 5 - 7 days for stock materials
Other Grade

Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov,

15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo,

40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo

Standard ASTM GB EN DIN
Application Structure and Industrial

Regular Standard Size of our 23MnNiMoCr54 Round Bar in Stock

Standard Diameter 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300

23MnNiMoCr54 steel

23MnNiMoCr54 steel is based on low carbon steel, by adding Mn, Ni, Mo, Cr, Al and other alloy elements, through the solid solution strengthening, grain boundary strengthening and second phase particle strengthening of these elements, to improve the strength, plasticity and toughness of the steel, at the same time by controlling the harmful elements s, P in the steel to improve the fatigue life of the chain.

  • MATERIAL TECHNICAL DATA SHEET - Grade 23MnNiCrMo5-4
  • MATERIAL TYPE - hot rolled bar, square bar
  • MATERIAL STANDARDS - DIN 17115
  • MELTING PROCESS - Consumable electrode remelted steel
  • H S CODE For Customs - 7228 4000 / 7228 5000 / 7228 6000
  • OFFICIAL TEST REPORT - issued by TUV - SGS - BV

CHEMICAL COMPOSITIONS (mass weight - %)
Carbon, C (％): 0.20 ~ 0.26
Silicon, Si (％): ≤ 0.25
Manganese, Mn (％): 1.10 ~ 1.40
Phosphorus, P (％)≤: 0.020
Sulfur, S (％)≤: 0.015
Chromium, Cr (%): 0.40 ~ 0.60
Molybdenum, Mo (%): 0.50 ~ 0.60
Nickel, Ni (%): 0.90 ~ 1.10
Copper, Cu (%): ≤ 0.20
Nitrogen, N (%): ≤ 0.012
MECHANICAL PROPERTIES UNDER ROOM TEMP.
Mechanical property ≥|σs/MPa: 1130
Mechanical property ≥|σb/MPa: 1020
Mechanical property ≥|δ5(%): 10.0
Mechanical property ≥|AkU /J: 60.0
TYPICAL APPLICATIONS
Alloy structural steels are widely used in the filed of ship, vehicle, airplane, guided missile, weapons, railway, bridges, pressure vessel, machine tools, mechanical components with a bigger sectional size and so on.
Power generation – turbine fasteners – boiler support rods, Process plant – fasteners.
Mechanical gears, gear shaft, main axis, valve rod.
Mechanical parts - connecting rod, bolt and nut, Multidiameter shaft, Pressure vessel.
FORMS & DIMENSIONS
Round bar / Wire rod (Diameter): 5.5mm to 550mm
Square bar / Flat bar: 3mm to 800mm
Length: Fixed length or random length or based on the customer's special requirement.
Heavy/middle plate via hot rolled: T60 - 400mm X W50 - 1000mm X L1000 - 12000mm
Forging piece: stepped shafts, other different shapes based on OEM.
Alloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm DiameterAlloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm DiameterAlloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm DiameterAlloy 23MnNiMoCr54 Round Bar GB Standard Steel Round Bar Hot Rolled 10 - 300mm Diameter
