Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
Specifications
Brand Name :
DELTA
Model Number :
inconel 625
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Sheet & Plate
Grade :
inconel 625
Thickness :
0.5 - 30.0mm
Standard size :
1000*2000mm 1219*2438mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1 NO.4 NO.8
Description

Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets

Material
Monel/Inconel/Hastelloy/Duplex Steel/PH Steel/Nickel Alloy
Shape
Round,Forging,Ring,Coil,Flange,Disc,Foil,Spherical,Ribbon,Square,Bar,Pipe,Sheet
Grade
Duplex: 2205(UNS S31803/S32205),2507(UNS S32750),UNS S32760(Zeron 100),2304,904L
Others:253Ma,254SMo,654SMo,F50(UNSS32100)F60,F61,F65,1J22,N4,N6 etc
Alloy : Alloy 20/28/31
Hastelloy:HastelloyB/ -2/B-3/C22/C-4/S/ C276/C-2000/G-35/G-30/X/N/g
Hastelloy B / UNS N10001,Hastelloy B-2 / UNS N10665 / DIN W. Nr. 2.4617,Hastelloy C,
Hastelloy C-4 / UNS N06455 / DIN W. Nr. 2.4610,Hastelloy C-22 / UNS N06022 / DIN W. Nr. 2.4602,
Hastelloy C276 / UNS N10276 / DIN W. Nr. 2.4819,Hastelloy X / UNS N06002 / DIN W. Nr. 2.4665
Haynes: Haynes 230/556/188
Inconel 600/601/602CA/617/625/713/718/738/X-750,Carpenter 20
Inconel 718 / UNS N07718 / DIN W. Nr. 2.4668,Inconel 601 / UNS N06601 / DIN W. Nr. 2.4851,
Inconel 625 / UNS N06625 / DIN W. Nr. 2.4856,Inconel 725 / UNS N07725,Inconel X-750 / UNS N07750 / DIN W. Nr. 2.4669,Inconel 600 /
UNS N06600 / DIN W. Nr. 2.4816
Incoloy: Incoloy 800/800H/800HT/825/925/926;
GH: GH2132,GH3030,GH3039,GH3128,GH4180,GH3044
Monel: Monel 400/K500/R405
Nitronic: Nitronic 40/50/60;
Nimonic: Nimonic 75/80A/90/A263 ;
Specification
Wire: 0.01-10mm
Strip: 0.05*5.0-5.0*250mm
Bar: φ4-50mm;Length 2000-5000mm
Pipe: φ6-273mm;δ1-30mm;Length 1000-8000mm
Sheet: δ 0.8-36mm;Width 650-2000mm;Length 800-4500mm

Inconel 625 Sheet & Plate - UNS N06625

High strength and corrosion resistant, Inconel 625® is a nonmagnetic, nickel-based alloy with a very broad operational temperature range (cryogenic to 2,000°F/1,093°C). Inconel 625® is known for its toughness, high fatigue strength, and oxidation resistance.

Inconel 625 Sheet & Plate for All Applications

Magellan Metals offers Inconel 625 sheet in a range of standard thicknesses from 0.010” to 0.156”. Our Inconel 625 plate is available in thicknesses up to 4”. All our Inconel 625 sheet and plate meets a variety of national and international specifications, including:
  • ASTM B443
  • AMS 5599
  • AMS 5869
  • ISO 6208
  • and others (see table below)

Nominal Composition

C Mn Si P S Cr Mo Nb Co Ti Al Fe Ni
MIN – – – – – 20.00 8.00 3.15 – – – – –
MAX 0.10 0.50 0.50 0.015 0.015 23.00 10.00 4.15 1.00 0.40 0.40 5.00 BAL

Typical Mechanical Properties

Condition Heat Treatment Tensile Strength Suggested Operating Conditions
Annealed 1925-2050oF (1050-1120°C) 120 – 150 ksi (830-1100 MPa) -300°F to 1800°F (-184°C to 980°C)
Spring Temper – 200 – 250 ksi (1380 – 1724 MPa) -300°F to 700°F (-184°C to 370°C)

We also offer Inconel 625 wire, bar, tube, pipe, fittings, flanges, forgings, and welding rod.

Product Form Size range from Size range to
Alloy 625 pipe 0.5 in 8 in
Alloy 625 coil 0.25 mm 3.18 mm
Alloy 625 welding wire 0.5 mm 3.175 mm
Alloy 625 sheet & plate 0.25 mm 76.2 mm
Alloy 625 round bar 12 mm 260 mm
Alloy 625 pipe fittings 0.5 in 8 in
Alloy 625 flanges 0.5 in 8 in

Applications include:

  • Honeycomb
  • Springs
  • Seals
  • Bellows
  • Diaphragms
  • Land-based turbine components
  • Aircraft exhaust
    ducting
  • Heat exchangers

Industries supplied include:

  • Automotive
  • Marine
  • Chemical Processing
  • Power Generation
  • Nuclear
  • Aerospace

Inconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy SheetsInconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy SheetsInconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy SheetsInconel 625 Nickel Alloy Sheet Cold Rolled 0.4 - 3.0mm 4ft*8ft UNS N06625 Alloy Sheets
