EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing
Specifications
Brand Name :
DELTA
Model Number :
hastelloy c276
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Sheet & Plate
Grade :
hastelloy c276
Thickness :
0.5 - 30.0mm
Standard size :
1000*2000mm 1219*2438mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1 NO.4 NO.8
Description

EN 2.4819 / C276 Nickel Alloy Hastelloy UNS N10276 Plate Hot Rolled NO.1 Finishing

Product Type Hastelloy C276 ASTM B575 Sheet, Hastelloy C276 ASTM B575 Plate
Specification ASTM B575 / ASME SB575
Tolerances (width / thickness)
  • EN 10258/ DIN 59381)
  • EN 10151 2.4819 Hastelloy C-276 Strips
  • EN 10088 Hastelloy C276 SB575 strips
Dimensions
  • Cold rolled Alloy C276 Plates 0.5-6.4 mm
  • Hot rolled Alloy C276 Plates 3.0–10.0 mm
Thickness 0.1 to 100 mm Thk
Width 10-2500mm
Length 2m, 2.44m, 3m, or as required
Finish SATIN, 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), No.1 finish hot rolled, 1D, No.4, BA, 8K, hairline, brush, mirror etc.
Hardness Soft, Hard, Half Hard, Quarter Hard, Spring Hard
variety of shapes Coils, Foils, Plates, Sheet, Strip, Plain Sheet, Checker Plates, Rolling Sheet, Flats, Clad Plates, Flat Sheet, Shim Sheet, Rolls, Blank (Circle), Rolling Plates, Flat Shim, soft annealed, descaled, tread Plates, sheared, annealed

Hastelloy C276 Sheet is a high-quality, corrosion-resistant alloy made from nickel, molybdenum, and chromium. It has excellent resistance to hot oxidizing and reducing media, as well as to a wide range of other contaminants.

Hastelloy C276 Sheets is used in many industries, including the pulp and paper industry, oil and gas production, and chemical processing.

Equivalent Grades of Hastelloy C-276 Shim

STANDARD WERKSTOFF NR. UNS JIS EN DIN ISO GOST OR
Hastelloy C276 2.4819 N10276 NW 0276 NiMo16Cr15W 17750 6208 ХН65МВУ ЭП760

Chemical Composition of Hastelloy C276 Sheet

C Mn Si S

Co

 Ni Cr Fe Mo P
0.010 max 1.00 max 0.08 max 0.03 max 2.50 max 50.99 min* 14.50 – 16.50 4.00 – 7.00 15.00 – 17.00 0.04 max

Mechanical Properties of B575 Hastelloy C276 Sheet

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.89 g/cm3 1370 °C (2500 °F) Psi – 1,15,000 , MPa – 790 Psi – 52,000 , MPa – 355 40 %

Hastelloy C276 Application

There are many sectors and industries consuming ASTM B575 Hastelloy C276 Sheet like:

Organic chloride process equipment Evaporators, heat exchangers, filters and mixers used in sulfuric acid environments
Equipment for flue-gas desulfurisation plants Equipment for processes utilizing halide or acid catalysts
Digesters and bleach plants in the paper industry Sulfuric acid reactors
Components exposed to sour gas Military
Defence & Aerospace industries Used for Oil and Gas
