Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Hot Rolled SS Plate 304 / 1.4301 / SUS304 / 06Cr18Ni9 3.0 - 60.0mm ASTM A240
Specifications
Brand Name :
DELTA
Model Number :
201 202 304 316L 309S 310S 321 347 904L 2205 2507.etc
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
2400 - 3500 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
5Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
wooden pallets + waterproof paper
Products :
stainless steel sheet & plate
Grade :
201 304 316L 430.etc
Standard size :
1000*2000mm 1219*2438mm 1500*6000mm
Thickness :
0.6 - 60.0mm
Brand :
TISCO BAOSTEEL POSCO LISCO
Loading Port :
Shanghai Port
MOQ :
500 kgs
Packing :
wooden pallets + waterproof paper
Description

Hot Rolled 304 / 1.4301 / SUS304 / 06Cr18Ni9 SS Plate 3.0 - 60.0mm ASTM A240 from TISCO

Products Stainless Steel Plate
Thickness 0.6 - 60.0mm
Width 1000mm 1219mm 1500mm 1800mm 2000mm or other width as request
Length 2000mm 2438mm 3000mm 6000mm or other length as request
Grade 201 202 301 304 304L 304H 309S 310S 316L 316Ti 317L 321 347 409L 410 420 430 431 436L 439 441 443 444 2205 2507 904L 600 625 800 825 718 253MA 254SMO.etc
Service Laser Cutting, Surface processing, bending
Brand TISCO BAOSTEEL POSCO LISCO JISCO
Standard ASTM JIS GB DIN EN BS
Certificate ISO MTC C/O F/E
Packing Wooden pallets and waterproof paper
Deliver time 5 - 15 days
Loading port Shanghai Port

Our 304 Stainless Steel Sheet & Plate in Stock

304 Stainless Steel Plate & Sheet in Stock
0.3*1219*2438 3.0*1500*6000mm 30*1500*6000mm 0.3*1000*2000mm
0.4*1219*2438 4.0*1500*6000mm 35*1500*6000mm 0.4*1000*2000mm
0.5*1219*2438 5.0*1500*6000mm 40*1500*6000mm 0.5*1000*2000mm
0.6*1219*2438 6.0*1500*6000mm 45*1500*6000mm 0.6*1000*2000mm
0.8*1219*2438 8.0*1500*6000mm 50*1500*6000mm 0.8*1000*2000mm
1.0*1219*2438 10.0*1500*6000mm 55*1500*6000mm 1.0*1000*2000mm
1.2*1219*2438 12.0*1500*6000mm 60*1500*6000mm 1.2*1000*2000mm
1.5*1219*2438 14.0*1500*6000mm 65*1500*6000mm 1.5*1000*2000mm
2.0*1219*2438 16.0*1500*6000mm 70*1500*6000mm 2.0*1000*2000mm
2.5*1219*2438 20.0*1500*6000mm 75*1500*6000mm 2.5*1000*2000mm
3.0*1219*2438 25.0*1500*6000mm 80*1500*6000mm 3.0*1000*2000mm

AISI 304 Stainless Steel (UNS S30400)

AISI 304 stainless steel (UNS S30400) is the most commonly used material in stainless steels, and is usually purchased in an annealed or cold worked state. Because SS304 contains 18% chromium (Cr) and 8% nickel (Ni), it’s also known as 18/8 stainless steel. Type 304 has good processability, weldability, corrosion resistance, heat resistance, low temperature strength and mechanical properties, good hot workability such as stamping and bending, and no heat treatment hardening. SS 304 is widely used in the industrial use, furniture decoration, food and medical industry, etc.

AISI 304L is the low carbon version of 304 stainless steel, AISI 303 is a free-machining steel, basically a variant of SS304, which increases the phosphorus (P) and sulfur (S) content and improves the machinability. AISI 316 is better than 304 in certain properties, corrosion resistance and heat resistance, etc. For more information, please check 304 vs 304L stainless steel and 304 vs 316 stainless steel.

Chemical Composition of 304 Stainless Steel

Chemical Composition, %
AISI (UNS) C, ≤ Si, ≤ Mn, ≤ P, ≤ S, ≤ Cr Ni N, ≤ Product
304 (UNS S30400) 0.07 0.75 2.00 0.045 0.030 17.5-19.5 8.0-10.5 0.10 Plate, Sheet, and Strip
0.08 1.00 2.00 0.045 0.030 18.0-20.0 8.0-11.0 – Bars and Shapes

SS304 Stainless Steel Mechanical Properties

Datasheet-2, the tables below list SS304 material mechanical properties including yield strength, tensile strength, elongation and hardness, etc.

Mechanical Properties, data are for 25.4 mm (1 in.) diameter bar
Steel (UNS) Tensile strength, MPa (ksi) Yield strength, MPa (ksi) Elongation in 50 mm (2 in.), % ≥ Reduction in area (%) Hardness (HB) Condition
AISI 304 (UNS S30400) 585 (85) 235 (34) 60 70 149 Annealed bar
690 (100) 415 (60) 45 212 Annealed and cold drawn
860 (125) 655 (95) 25 275 Cold drawn high tensile

Standard Specification of 304 Stainless Steel Plate

ASTM type 304 stainless steel equivalent material is listed in the table below, including ISO, European EN (Germany DIN, British BSi, France NF…), Japanese JIS and Chinese GB standard (For reference).

Notes:

  1. DIN 17440 has been replaced by DIN EN 10088-2.
  2. Chinese stainless steel grade 0Cr18Ni9 is an old designation, and has been replaced by the new name 06Cr19Ni10.
  3. ASTM A240/A240M – Standard Specification for Chromium and Chromium-Nickel SS Plate, Sheet, and Strip for Pressure Vessels and for General Applications.
  4. ASTM A276/A276M – Standard Specification for SS Bars and Shapes.
  5. JIS G4304 :2005 – Hot rolled stainless steel plate, steel sheet and steel strip.
  6. GB/T 1220: 2007 – Stainless steel bars.
  7. GB/T 3280: 2015 – Cold rolled stainless steel plate, steel sheet and steel strip.

Applications

AISI 304 stainless steel is widely used in petroleum & chemical industry, metallurgical machinery, aerospace industry, food processing equipment, instruments, household appliances and hardware manufacturing industries.

SS304 material is made into a great many intermediate products such as steel sheet & plate, steel tube & pipe, steel bar & flat, rod & wire, etc.

Final products such as all kinds of kitchen ware, tableware, medical device, machinery and parts, wire mesh, filters, architectural and decorative products, etc.
