17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm
Specifications
Brand Name :
DELTA
Model Number :
201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
2400 - 3500 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Shape :
round
Standard :
ASTM EN GB JIS
Grade :
201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507.etc
Application :
Construction,Industry,surgical tools,seawater equipment.,kitchenware
Length :
Customers' Requirements,5.8m,6m,2m-6m,or as required
Size :
custom as request
Packing :
Standard Seaworthy Package,In wooden cases(for FCL/ LCL shipment)
Service :
Cutting, surface finishing
Description

17-4PH Stainless Steel Bright Bar / Grade 17-4 Stainless Steel Shaft Diameter 4 - 100mm

Products Stainless Steel Bar
Grade 17-4PH
Diameter 5 - 350mm
Length 6m or custom cutting any length as request
Finishing Bright Bar / Black Surface
Heat Treatment Solid Solution , ageing
Surface Process Polishing , Peeling
Other Grade

201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431

2205 2507 904L 254SMO 416 431 440A/B/C.etc
MOQ 500 Kgs
Loading Port Shanghai Port
Processing Cutting
Packing Wooden box or wrapping by PP bag

This grade of stainless steel has a typical density of 7.75kg/dm³ and can be magnetised. 17 4PH finds specific use in applications where a combination of unusually high strength and moderate corrosion resistance is a determining factor. The alloy has similar corrosion resistance characteristics when compared to 304 stainless steel.

Chemical Composition of 17-4PH Stainless Steel

Carbon 0.07% (Max)
Silicon 1.00% (Max)
Manganese 1.00% (Max)
Phosphorous 0.040% (Max)
Sulfur 0.030% (Max)
Chromium 15%-17.5%
Molybdenum 0.50% (Max)
Nickel 3%-5%
Copper 3%-5%

Physical Properties of 17-4PH Stainless Steel

Condition Tensile Yield Enlongation Reduction of Area Hardness
H900 190KSI 170KSI 10% 35% 35 HRC
H1025 155KSI 145KSI 12% 45% 40 HRC
H1075 145 125 13 45 33-39 HRC
H1150 135 105 16 50 28-37 HRC
H1150D 125 105 16 50 25-33 HRC

17-4 Stainless Steel Processing

Achieve superior hardness from welding after heat treatment. Machining conditions differ with the firmness of the element. Different levels of strength and hardness can be achieved depending on the temperature it is heat treated at. The ASTM designation is A564 and common conditions are H900, H1025, H1075, H1150, and H1150D.

TYPICAL APPLICATIONS

17-4 stainless steel is known for its high strength, corrosion resistance, and toughness. Because of these traits, it is often used in the aerospace, medical, and food processing industries, as well as in construction, oil and gas, and transportation.

Additionally, 17-4 PH stainless steel is often used in the manufacturing of gears, valves, pumps, and fasteners, as well as in the production of molds and dies. The alloy's high strength and corrosion resistance properties make it an ideal material for use in harsh and demanding environments.
