EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel
Specifications
Brand Name :
BAOSTEEL BENSTEEL HBIS XINGCHENG
Model Number :
S355J2
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
600-800 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Steel Plate
Thickness :
3.0-260.0mm
Width :
1000-2200mm
Length :
2000-12000mm
Standard :
ASTM EN GB
Other Grade :
SA515GR70,AISI5140 AISI4140 Q355B S235B.etc
Brand :
BAOSTEEL XINYU XINGCHENG HBIS
Service :
Cutting
Description

EN 10025-2 S355J2 Steel Plate Thickness 2.0 - 150.0mm Q355D Plate Low Temperature Steel


Products Specification of S355J2 Steel

Products Name S355J2 Steel Plate
Thickness 3.0 - 200mm
Width 100 - 2200mm custom cutting any size as request
Length 6m 8m 10m 11.5m 12m or cutting any length as request
Standard ASTM JIS GB EN
MOQ 500 Kgs
Deliver time 7 - 14 days
Loading Port Shanghai Port
Packing wooden pallets
Equal Grade S355J2 Q355D
Other Grade 4130 / 4140 / 5140 / 4340 / S355J2/JR S235 1045 1020 65Mn.etc
Service Cutting, Heat treatment

S355J2 Steel (Material 1.0577)

S355J2 steel (1.0577) is a quality grade of S355 steel, which is one of the non-alloy structural steels commonly used in Europe. According to EN 10025-2: Hot rolled products of structural steels, S355 steel is divided into 4 quality grades, namely:

  • S355JR (1.0045),
  • S355J0 (1.0553),
  • S355J2 (1.0577), former names: S355J2G3 and S355J2G4 in EN 10025:1990,
  • S355K2 (1.0596), previous names: S355K2G3 and S355K2G4 in EN 10025:1990.

EN 10025 S355J2 equivalent ASTM A992/A992M; Australian AS/NZS 3678: Grade 350 L20; Canadian G40.20/G40.21: 350WT (55WT); Chinese GB/T 1591: Q355D; and Indian standard IS 2062: E350.

EN 10025 S355J2 Meaning

S355J2 Meaning: “S” stands for “Structural steel”; 355 indicates that the material has a minimum yield strength of 355 MPa when the nominal thickness is ≤ 16mm; and “J2” indicates that the material has a minimum impact energy of 27J at -20°C (-4 °F).

S355J2 Steel Properties

S355J2 steel properties are listed in the datasheet below, including chemical composition, physical and mechanical properties, etc.

Chemical Composition

Chemical composition based on heat analysis.

Chemical Composition, % (≤)
Standard Steel (Material Number) C Si Mn P S Cu N Method of deoxidation
EN 10025-2 S355J2 (1.0577) 0.20 0.55 1.60 0.025 0.025 0.55 – Fully killed

Note: For carbon content (C) and nominal thickness (t)

  • C ≤ 0.20 % when t ≤ 16mm,
  • C ≤ 0.22 % when t > 30 mm,
  • C by agreement when sections with nominal thickness > 100 mm.
  • For long products the P and S content can be 0.005 % higher.
Chemical Composition (Product Analysis), % (≤)
Standard Steel (Material Number) C Si Mn P S Cu N Method of deoxidation
EN 10025-2 S355J2 (1.0577) 0.23 0.6 1.70 0.035 0.035 0.60 – Fully killed

Note: For carbon content (C) and nominal thickness (t)

  • C ≤ 0.23 % when t ≤ 16mm,
  • C ≤ 0.24 % when t > 30 mm,
  • C by agreement when sections with nominal thickness > 100 mm.
  • For long products the P and S content can be 0.005 % higher.

Mechanical Properties

S355J2 mechanical properties at room temperature are listed in the datasheet below, including tensile strength, yield strength, and elongation, etc.

Yield Strength, Mpa, ≥
Steel Grade (Steel Number) t≤16 16< t ≤40 40< t ≤63 63< t ≤80 80< t ≤100 100< t ≤150 150< t ≤200 200< t ≤250 250< t ≤400
S355J2 (1.0577) 355 345 335 325 315 295 285 275 265
Tensile Strength, Mpa, ≥
Steel Grade (Material Number) t<3 3 ≤ t ≤ 100 100 < t ≤400
S355J2 (1.0577) 510-680 470-630 450-600

Note:

  • 1 MPa = 1 N/mm2
  • t = Nominal Thickness (mm)

Physical Properties

  • Density: 7.85 g/cm3 (0.284 lb/in3)
  • Melting point: 1450-1530 °C (2640-2800 °F)

Elongation After Fracture

Minimum percentage elongation after fracture

Elongation after fracture (%, ≥), L0 = 80 mm
≤1 1< t ≤1.5 1.5< t ≤ 2 2< t ≤ 2.5 2.5< t < 3 Orientation of test pieces
14 15 16 17 18 Parallel
12 13 14 15 16 Transverse
Elongation after fracture (%, ≥), L0 = 5.65 √So
3≤t≤40 40< t ≤63 63 < t ≤100 100 < t ≤ 150 150 < t ≤ 400 Orientation of test pieces
22 21 20 18 17 Parallel
20 19 18 18 17 Transverse

Material S355J2 Equivalent Steel Grades

S355J2 steel equivalent materials are listed below, including ASTM, German DIN, ISO, Australian, Canadian, Chinese and Indian IS standard, etc.

S355J2 Steel Equivalent Material
European Union USA Germany ISO Australia Canada China Indian
Standard Grade (Material Number) Standard & Grade Grade Standard Grade Standard Grade Standard Grade Standard Grade, SI (Imperial) Standard Grade Standard Grade
EN 10025-2 S355J2 (1.0577);
S355J2G3		 ASTM A992/A992M;
ASTM A572/A572M		 A572 Grade 50 [345];
A992		 DIN 17100 St 52-3N ISO 630-2 S355D AS/NZS 3678 Grade 350 L20 G40.20/G40.21 350WT (55WT) GB/T 1591 Q345D;
Q355D		 IS 2062 E350
