AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting
Specifications
Brand Name :
BAOSTEEL BENSTEEL HBIS XINGCHENG
Model Number :
Carbon Steel , Alloy Steel
Certification :
ISO 9001
Place of Origin :
China
MOQ :
10 kgs
Price :
560 - 880 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Alloy Steel Plate
Thickness :
3.0 - 200.0mm
Width :
1000-2200mm
Length :
2000-12000mm
Standard :
ASTM EN GB
Other Material :
Carbon Steel, Alloy Steel, Stainless Steel
Brand :
BAOSTEEL XINYU XINGCHENG HBIS
Service :
Cutting
Description

AISI4140 42CrMo4 Scm440 Alloy Steel Plate Thickness 10 - 160.0mm Custom Cutting

Products Specification

Product Alloy Steel Plate/Sheet
Standard ASTM A285,ASTM A283,SA516,SA517,EN10025-2-2004,ASTM A572,ASTM A529,ASTM A573,ASTM A663,JIS G3101-2004,ASTM A678,ASTM A588,ASTM A242,etc
Material A36,SS400,A283,Gr.A,.Gr.B.Gr.C,A285

Gr.A,.Gr.B.Gr.C,Q235,Q195,Q215,S185,SM400, S235J0,S235JR,S235J2,Q275,Gr50,GR55,GR.65,GR.A,

S275JR,S275J0,E295,SS490, SS540,GR.60,GR.70,S355J0,SM570,E335,S235J2W,Q355,SMA490,S355J2W, Q265,P235GH,SB410,SPV235,SGV410,SG255,P265GH,SB450,SG295,P295GH,etc

15CrMo 30CrMo 42CrMo 65Mn12CrNiMoV 8620H 4340 4140 4150 5140 .etc
Size Thickness:6.0-400mm

Width:1250mm,1500mm,1800mm,2000mm,2200mm,2500mm,etc Length:1000mm,1500mm,2000mm,3000mm,5000mm,8000mm,1000m,etc
Surface Coated,Embossed,Brushed,Polished,Anodized,etc
Application Boiler Plate Container Plate Flange Plate Ship Plate
MOQ 1 ton. Sample order is acceptable. Please contact for details.
Package Standard Sea Worthy Packing or customized

AISI 4140 Alloy steel material stockholders and suppliers from China-OTAI SPECIAL STEEL . we have more 16 years experience in 4140 steel plate, round bar, flat bar, square supply.AISI 4140 alloy steel is chromium, molybdenum, manganese containing low alloy steel. It has high fatigue strength, abrasion and impact resistance, toughness, and torsional strength. The following datasheet gives an overview of AISI 4140 alloy steel.

4140 alloy steel material is a high quality Quenched and Tempered Alloy Structural steel, It belong to the high quality medium carbon alloy steel, Oil Quenched & Tempered Hardenss is 28-34 HRC.4140 Annealing delivery hardenss less than 250HB.

1. SAE AISI 4140 steel Form of Supply

ASTM / AISI 4140 Alloy structural steel, we can supply the round bar, steel flat bar, plate, hexagonal steel bar and square, block. 4140 alloy steel Round bar can be cut to your required lengths as one offs or multiple cut pieces. Rectangular pieces can be cut from flat bar or plate to your specific sizes. Ground tool steel bar can be supply, providing a quality precision finished bar to tight tolerances.

  • Round
  • sheet
  • Square
  • Plate
  • Hexagonal
  • Pipe

2. AISI 4140 equivalent material

  • JAPAN : JIS SCM440 alloy steel
  • GERMANY: DIN WN-r 1.7255 / 42CrMo4 steel alloy
  • CHINA : GB 42CrMo steel
  • BRITISH: BS 708M40

3. AISI 4140 alloy steel Chemical composition

ASTM A29/29M C Si Mn Cr Mo P S
4140 0.38~0.43 0.15~0.35 0.75~1.00 0.80~1.10 0.15~0.25 ≤0.035 ≤0.040
DIN WN-r C Si Mn Cr Mo P S
1.7225 0.38~0.45 ≤0.40 0.60~0.90 0.90~1.20 0.15~0.30 ≤0.035 ≤0.035
GB/T C Si Mn Cr Mo P S
42CrMo 0.38~0.45 0.17~0.37 0.50~0.80 0.90~1.20 0.15~0.25 ≤0.030 ≤0.030
BS C Si Mn Cr Mo P S
708M40 0.36~0.44 0.10~0.35 0.70~1.00 0.90~1.20 0.15~0.25 ≤0.035 ≤0.035
JIS C Si Mn Cr Mo P S
SCM440 0.38~0.43 0.15~0.35 0.60~0.85 0.90~1.20 0.15~0.30 ≤0.030 ≤0.030

4. Applications

DIN 4140 Tool steel is a alloy structural steel, 4140 is used for engineering structural, like high tensile shafts, bolts and nuts, gears, pinions and spindles. Locomotive traction with the big gear, supercharger drive gear, pressure vessel, rear axle, gear load of connecting rod and a spring clip,4140 can also be used to under 2000 m deep well of oil drill pipe joint and the fishing tool, and can be used for bending machine mould, etc

5. Supply Size range

Hot Rolled 4140 steel bar: Ø5mm-200mm

Forging 4140 steel bar: Ø140mm-3000mm

Hot rolled 4140 steel plate: Thickness 10mm-200mm x width 100-2300mm

Forged 4140 material steel plate: Thickness 150-1500mm x Width 100 x 3000mm

Others 4140 material have not specified size, pls contact our experienced sales team.
