42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade
Specifications
Brand Name :
BAOSTEEL BENSTEEL HBIS XINGCHENG
Model Number :
Carbon Steel , Alloy Steel
Certification :
ISO 9001
Place of Origin :
China
MOQ :
10 kgs
Price :
560 - 880 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Alloy Steel Plate
Thickness :
3.0 - 200.0mm
Width :
1000-2200mm
Length :
2000-12000mm
Standard :
ASTM EN GB
Other Material :
Carbon Steel, Alloy Steel, Stainless Steel
Brand :
BAOSTEEL XINYU XINGCHENG HBIS
Service :
Cutting
Description

42CrMo4 Alloy Steel Plate & 1.7225 Steel Plate EN DIN Standard Equal Grade

Products Specification

Product Alloy Steel Plate/Sheet
Standard ASTM A285,ASTM A283,SA516,SA517,EN10025-2-2004,ASTM A572,ASTM A529,ASTM A573,ASTM A663,JIS G3101-2004,ASTM A678,ASTM A588,ASTM A242,etc
Material A36,SS400,A283,Gr.A,.Gr.B.Gr.C,A285

Gr.A,.Gr.B.Gr.C,Q235,Q195,Q215,S185,SM400, S235J0,S235JR,S235J2,Q275,Gr50,GR55,GR.65,GR.A,

S275JR,S275J0,E295,SS490, SS540,GR.60,GR.70,S355J0,SM570,E335,S235J2W,Q355,SMA490,S355J2W, Q265,P235GH,SB410,SPV235,SGV410,SG255,P265GH,SB450,SG295,P295GH,etc

15CrMo 30CrMo 42CrMo 65Mn12CrNiMoV 8620H 4340 4140 4150 5140 .etc
Size Thickness:6.0-400mm

Width:1250mm,1500mm,1800mm,2000mm,2200mm,2500mm,etc Length:1000mm,1500mm,2000mm,3000mm,5000mm,8000mm,1000m,etc
Surface Coated,Embossed,Brushed,Polished,Anodized,etc
Application Boiler Plate Container Plate Flange Plate Ship Plate
MOQ 1 ton. Sample order is acceptable. Please contact for details.
Package Standard Sea Worthy Packing or customized

The 42CrMo4 type of steel is used for tempering and quenching, in part because it has such a good combination of toughness and strength in the tempered and quenched condition. Once the oil quenching is complete, the steel itself will be through-hardened up to ø60 mm bar diameter. The steel itself is applicable to induction hardening. This is a special high-grade steel that provides a great amalgamation of both toughness and strength, and it is usually available in a mix of microstructure, that is, austenite and martensite. There are different European standards that cover the specification of the steel in various forms and processing conditions. The special grade of this steel is always subjected to M-treatment to provide the best machinability properties.

Composition of the 42CrMo4 :

C
Cr
Mn
Mo
P
S
Si
0.38-0.45%
0.90-1.20%
0.60-0.90%
0.15-0.30%
0.035%
0.035%
0.40% max.

The 42CrMo4 type of alloy steel has a chemical composition that looks like this:

  • C: 0.38-0.45%
  • Cr: 0.90-1.20%
  • Mn: 0.60-0.90%
  • Mo: 0.15-0.30%
  • P: 0.035%
  • S: 0.035%
  • Si: 0.40% max.

In addition, these steels are sold on the global market as per various European standards, including steel tubes, steel die forgings, cold redrawn forms, cold-rolled narrow steel strips, seamless circular steel tubes, flat plates, and rods, wires, and bars. They are even available in round bar sizes 10 to 3000 mm in diameter and in flat plates with a thickness of 10 to 1500 mm and a width of 200 to 3000 mm, as well as other steel sizes and shapes that you can have custom made.

Other Characteristics

For the alloy steel manufacturer that makes the 42CrMo4 type of steel, they know that this high-grade steel has low weldability but can be welded when friction is used. Of course, you still have to take precautions so there are no unwanted weakening microstructures in the weld zone.
