C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
C11000 CU-ETP / CW004A Copper Plate Sheet Flat Plates Good Surface And Smooth Edge
Specifications
Brand Name :
DELTA
Model Number :
CU-ETP
Certification :
ISO
Place of Origin :
CHINA
MOQ :
50 kgs
Price :
10 - 12.2 USD/Kg
Payment Terms :
T/T, L/C
Supply Ability :
5 Ton per week
Delivery Time :
10 days
Packaging Details :
carton box, wooden box
Products :
Copper Plate Sheet
Material :
CU-ETP / C11000 / C110
Thickness :
0.5 - 60.0mm
Width :
10 - 1500mm
Length :
within 6m
MOQ :
50 kgs
Type :
Plate, sheet, coil , strip, bars
Packing :
carton box, wooden box
Description

Copper Plate Sheet C11000 CU-ETP / CW004A Flat Plates Good Surface and Smooth Edge

Products Specification

Copper Sheet,Copper Plate
Material
C10100,C10200,C10300,C10400,C10500,C10700,C10800,C10910,C10920,
C10930,C11000,C11300,C11400,C11500,C11600,C12000,C12200,C12300,
C12500,C14200,C14420,C14500,C14510,C14520,C14530,C17200,C19200,
C21000,C23000,C26000,C27000,C27400,C28000,C33000,C33200,C37000,
C44300,C44400,C44500,C60800,C63020,C65500,C68700,C70400,C70600,
C70620,C71000,C71500,C71520,C71640,C72200,etc.
Specifications
Thickness
0.1mm-200mm
Width
10mm-2500mm
Length
10mm~12000mm,or as required.
Price Term
Ex-work, FOB, CFR, CIF, etc.
Payment Term
T/T, L/C, Western Union, etc.
Delivery Time
According to order's quantity.
MOQ
100Kgs.
Export To
Singapore,Indonesia,Ukraine,Korea,Thailand, Viet Nam, Saudi Arabia, Brazil,
Spain, Canada, USA, Egypt, India, Kuwait, Dubai, Oman, Kuwait, Peru,
Mexico, Iraq,Russia,Malaysia, etc.

Pure copper appearance is purplish red, commonly known as "red copper", "red copper" or "red copper".Pure copper conducts electricity very well, ranking second only to silver among all metals, so it is used very widely in industry.T2 is a typical grade of pure copper, usually referring to red copper, or T2 unless otherwise specified.

STANDARDS:

CHINA

GB/T 5231-2012

GB/T 2529-2012

 T2,T11050
USA ASTM B187-2006 C11000
JAPAN

JIS H3100:2006

JIS H3140:2006[TJC STEEL]

JIS H3250:2006

 C1100
GERMANY DIN 1787:1973 E-Cu58,2.0065
DIN CEN/TS 13388:2008 Cu-ETP,CW004A

CHEMICAL COMPOSITION(%):

GRADE T2 C11000 C1100 CW004A
Cu ≥99.90 ≥99.90 ≥99.90 ≥99.90
Ag — ≤0.03
Bi ≤0.001 — — ≤0.0005
Sb ≤0.002 — — —
As ≤0.002 — — —
Fe ≤0.005 — — —
Pb ≤0.005[TJC STEEL] — — ≤0.005
S ≤0.005 — — —
O — — — ≤0.040

PERFORMANCE CHARACTERISTICS:

1. Excellent electrical and thermal conductivity, good ductility, deep drawing performance, corrosion resistance and atmospheric corrosion performance, can be welded and brazed.

2. Trace amount of oxygen is easy to cause "hydrogen embrittlement", not suitable for processing and use in high temperature (such as BBB 0 370℃) reducing atmosphere.

Application of Cu-ETP Copper Plate Sheet

Cu-ETP has the advantages of electric conduction and heat conduction of pure copper, and is widely used, such as wire and cable, sealing gasket, hardware, mold electrode, etc.
