Specifications
Brand Name :
DELTA
Model Number :
GR1 GR2 GR3 GR4 GR5 GR7
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Titanium bar
Grade :
GR1 GR2 GR3 GR4 GR5 GR7
Diameter :
4 - 300mm
Length :
custom any length as request
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
bright
Description

Titanium Bars & Rod ASTM B265 B348 Diameter 4 - 300mm Bright Titanium Bars

Titanium Alloy Bar / Rod

  • Titanium Bars
  • Material: Gr1,Gr2,Gr3,Gr4,Gr5,Gr9,Gr12,Gr23
  • Standard: ASTM B348,ASTM F67, ASTM F136,ASTM 4928
  • Dia:6.0-200mm
  • Piece Length (Bars Come In Commercial Lengths)
  • 6.0-14mm: Up to 3000mm
  • 15-60mm: Up to 4000mm
  • 61-200mm:Up to 6000mm

Technical Information:

We are capable of supplying all grades of commercial pure titanium and titanium alloys in accordance with AMS, ASTM specification or equivalent.

We have years of manufacturing experience with development and research and have the capability to produce difficult titanium alloy grades which related sensitive tests can be easily passed after checking by customers. All titanium bars will be done with 100%UT tests unconditionally, and the UT level can be AA or A1 or as per standard request, the best diameter tolerance we can reach is h6, and one special point we would like to show you is that the tensile strength can be more than 800MPA based on commercially pure titanium grade 4, also all titanium alloy can have higher tensile strength by using STA(Solution Treatment & Aging) and adjusting the chemical composition.

Regular titanium materials for titanium bar

Material Size Available Standards
Titanium CP1 (Grade 1) Diameter:3.0MM~250MM
Length:1000~6000mm
Customized sizes are available
best diameter tolerance:h6		 ASTM B348, AMS-4928
AMS-6931, AMS-T-9047 (6AL-4V Grade 5)
ASTM-F67 (CP Grades 1-4)
ASTM-F-136 (6AL-4V ELI)
Titanium CP2 (Grade 2)
Titanium CP3 (Grade 3)
Titanium CP1 (Grade 4)
Gr.9(Ti3AL2.5V)
Gr.5(Ti6AL4V)
Gr.7
Gr.11
Gr.12
GR.16
GR.17

Featured titanium materials for titanium bar

Featured Titanium alloy grades
Titanium 6Al-4V STA AMS 4904 AMS 4965 AMS 6930 AMS T-9046 STA AMS T-9047 STA
Titanium 8Al-1Mo-1V AMS 4916 AMS 4972 MIL-T-9046 MIL-T-9047
Titanium 6Al-2Sn-4Zr-2Mo AMS 4919 AMS 4976 AMS 4979 MIL-T-9046 AB-3 AB-4 MMS1203 DMS 2275
DMS 1879 MIL-T-9046 TY 3 CMP G AMS 4975 MIL T-9047 UNS R54620
Titanium 6Al-2Sn-4Zr-6Mo AMS 4981 MIL-T-9047 UNS 56260
Titanium 6Al-6V-2Sn AMS 4918 AMS 4936 AMS 4937 AMS 4971 AMS 4978 AMS 4979 MIL-T-9046 MIL-T-9047 UNS 56620
Titanium 3Al-2.5V ASTM B265 ASTM B337 ASTM B338 ASTM B348 ASTM B381 AMS 4943 AMS 4944 AMS 4945 MIL-T-9046 MIL-T-9047
Titanium 5Al-2.5Sn ASTM B265 ASTM B348 ASTM B381 AMS 4910 AMS 4924 AMS 4926 AMS 4966 MIL-T-9046 MIL-T-9047 COMP A
Titanium 15V-3Cr-3Sn-3Al AMS 4914, AMS 4922
Titanium 3Al-8V-6Cr-4Mo-4Zr AMS 4939 AMS 4957 AMS 4958 MIL-T-9046 MIL-T-9047 AMS 6921
Titanium 10V-2Fe-3Al AMS 4983 AMS 4984 AMS 4986 AMS 4987
Titanium 5Al-5Mo-5V-3Cr MIL-A-46077
ВT-9 (Ti-6,5Al-3,3Mo-1.5Zr-0,25Si) GB/T2965-20007, GJB2744A-2007

Feature:

  • Low Density
  • Excellent Corrosion Resistance in acid and alkali salt
  • High heat transfer capability
  • Good biocompatibility
  • Low elasticity module
  • Low thermal expansion coefficient
  • Superior strength-to-density ratios
  • Good strength at low and high temperature

Titanium Bars & Rod ASTM B265 B348 Diameter 4 - 300mm Bright Titanium BarsTitanium Bars & Rod ASTM B265 B348 Diameter 4 - 300mm Bright Titanium BarsTitanium Bars & Rod ASTM B265 B348 Diameter 4 - 300mm Bright Titanium BarsTitanium Bars & Rod ASTM B265 B348 Diameter 4 - 300mm Bright Titanium Bars
