Specifications
Brand Name :
DELTA
Model Number :
Nickel 201 / Nickel 200
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel bars
Grade :
UNS N02201 / Alloy 201
Diameter :
4 - 200mm
Length :
custom any length as request
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
Bright
Description

Nickel Alloy 201 Round Bar ASTM DIN EN Standard Alloy 200 Nickel UNS N02201 Bright Bar

Products Specification

Products Name UNS N02201 / Nickel 201 Bars
Standard ASTM B160
Diameter 4 - 200mm
Type hot rolled , cold drawn
Length 1m 2m 3m or custom any length as request
Other Shape Pipe, sheet , plate , strip, square , hexagonal,wire
MOQ 50 kgs
Loading Port Shanghai Port
Packing Wooden box
Deliver time 4 - 15 days

Alloy 201 (UNS N02201) is a commercially pure wrought nickel, with good mechanical properties and an excellent resistance to many corrosives. Nickel 201 has low carbon (0.02% max) for applications over 315°C it is mainly used for food processing equipment, chemical shipping drums, caustic handling equipment and piping, electronic parts, aerospace and missile components, rocket motor cases, magnetostrictive devices.

Chemical Composition Limits
Weight% Ni Cu Fe Mn C Si S
Nickel Alloy 200 99.0 min 0.25 max 0.40 max 0.35 max 0.15 max 0.35 max 0.01 max
Nickel Alloy 201 99.0 min 0.25 max 0.40 max 0.35 max 0.02 max 0.35 max 0.01 max

Typical Mechanical Properties

Material Tensile Strength Yield Strength (0.2% Offset) Elongation in 2" (%) Hardness
ksi MPa ksi MPa Brinnell (3000kg) Rockwell B
Nickel 200 55-75 380-520 15-30 105-210 55-40 90-120 45-70
Nickel 201 55-75 380-520 15-30 105-210 55-40 90-120 45-70

Nominal Results for Colled Rolled, Annealed Rod and Bar

Availability
Nickel 201 (UNS N02201) is available in Bar, Rods, Tube, Pipe, Plate, Sheet, Strip, Wire and Forging Stock. Nickel 210 Foil (Shim) is available in various thicknesses. View stock list for further information, Foil Stock List. For all stock availability contact Sales.

Features

Alloy 200 / 201 is similar in strength to mild steel in the annealed condition. The alloy offers exceptional resistance to caustic alkalis and good corrosion resistance in neutral and moderately reducing environments. Alloy 200/201 displays good mechanical properties over a wide temperature range.

Specifications

  • UNS N02201
  • BS 3072, BS 3073, BS 3074, BS 3075 and BS 3076 (NA12)
  • ASTM B160, ASTM B162, ASTM B 163, ASTM B 725 and ASTM B 730
  • SAE AMS 5553 Sheet, Strip
  • ASME SB-160, ASME SB-163 and Boiler Code Sections III, VIII, IV
  • DIN 17740, 17750, 17751, 17752, 17753 and 17754
  • Werkstoff Nr. 2.4061 and WS2.4068

We stock Alloy 200 / 201 in round bar, sheet, strip, round tube and hollow bar.

TYPICAL APPLICATIONS

Commercial applications for this engineering material include:

  • Food processing
  • Fluorine generation
  • Heat exchangers
  • Tank heads
  • Chemical processing & storage
  • Phenol storage & transportation
  • Sodium hydroxide production
  • Pressure vessels & vessel components
