EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
Specifications
Brand Name :
DELTA
Model Number :
617 / UNS N06617 / 2.4663
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel alloy bars
Grade :
617 / UNS N06617
Thickness :
0.6 - 20.0mm
Size :
1219*2438 1500*6000mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1
Description

EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled & Hot Rolled Alloy 617 Plate

Products Description

Product Name Alloy 617 Plate UNS N06617 / EN 2.4663 Plate
Technology Hot rolled , Cold rolled
Grade Inconel 600, Inconel 601, Inconel 625, Inconel 617, Inconel 690, Inconel 718, Inconel X-750
Incoloy A-286, Incoloy 800, Incoloy 800H, Incoloy 800HT
Incoloy 825, Incoloy 901, Incoloy 925, Incoloy 926
Monel 400, Monel K-500
Hastelloy C22, Hastelloy C-276, Hastelloy B-2, Hastelloy B-3, Hastelloy X
Specifications ASTM, UNS, JIS, EN, AFNOR
Surface 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Processing Service
Machining : Turning / Milling / Planing / Drilling / Boring / Grinding / Gear Cutting / CNC Machining
Deformation processing : Bending / Cutting / Rolling / Stamping
Delivery time 10-30 days subject to the clients' requirement and quantity
Package clients' requirement and Standard export sea-worthy packing
MOQ 1 ton

ALLOY 617 CR SHEETS, INCONEL ALLOY 617 SLATTING SHEETS, NICKEL ALLOY 617 COLD ROLLED PLATES, INCONEL UNS N06617 POLISHED COLD DRAWN PLATES

ALLOY 617 SHEETS, ASTM B168 ALLOY 617 PLATES, ASTM B168 ALLOY 617 CR SHEETS, GRADE 617 INCONEL MILL FINISH PLATES, INOX 2.4663 617 INCONEL ALLOY CR SHEET, INCONEL DIN 2.4663 POLISHED COLD DRAWN PLATE

INCONEL ALLOY 617 SHEETS, PLATES & COILS SPECIFICATION

Inconel Alloy 617 Sheets & Plates Standard ASTM B168/ ASME SB168
Trade name Inconel Alloy 617 Sheets & Plates
617 Alloy Sheets & Plates Dimensions JIS, AISI, ASTM, GB, DIN, EN, etc
Inconel 617 Sheets & Plates Width 1000mm, 1219mm, 1500mm, 1800mm, 4000mm, 2500mm, 3000mm, 3500mm, etc
ASTM B168 617 Inconel Alloy Sheets & Plates Length 4000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
617 Inconel Sheets & Plates Thickness 0.3 mm to 120 mm
Inconel 617 Sheets & Plates Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Alloy 617 Sheets & Plates Surface Finishing Hot rolled plate (HR), Cold rolled sheet (CR),2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, Chequered, embossed, hair line, sand blast, Brush, etching, SATIN (Met with Plastic Coated) etc.
Payment Terms Paypal, Western Union, T/T (Telegraphic Transfer or Wire Transfer), L/C or Trade Assurance 30% deposit & balance before shipping
Free Sample Yes if we have in stock
Value Added Services Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing
SB168 Inconel Alloy 617 Sheets & Plates Origin & Mills Japanese, Indian, USA, Korean, European, Russian, Ukraine (Strictly No China)
Inspection and Test Reports EN 10204 3.1, Mill Test Certificates, Chemical Reports, PMI Test Reports, Mechanical Reports, Third Party Inspection, NABL Approved Lab, Visual Inspection, Destructive Test and Non Destructive Test Reports
Marking
  • Specification
  • Grade
  • Nominal Sheet/Plate Sizes
  • Sheet Schedule or Thickness
  • Manufacturing Method (HR / CR)
  • Heat Number
  • Manufacturer’s Name or Custom Logo – on request
  • Marked Sheet/Plate Sample: ASTM B168 617 Inconel Sheet/Plate & Coils HEAT NO. XXXX
Outside Finish Finish as per customer Requirements
Delivery Condition Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Packing of Inconel 617 Sheets & Plates Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials Sizes and Specifications other than above can be on request
Inconel UNS N06617 Sheets & Plates Application & uses
  • Petroleum
  • Chemical plant
  • Power sector
  • Gas Industry
  • Hardware tools
  • Metallurgy
  • Machinery
  • Construction
  • Shipbuilding

ASTM B168 617 INCONEL ALLOY SHEETS, PLATES & COILS

Products Size
ASTM B168 617 Inconel Alloy Perforated Sheet ASTM B168 617 Inconel Alloy Plates Sizes 3.0–10.0 mm
ASTM B168 617 Inconel Alloy Sheet ASTM B168 617 Inconel Alloy Chequered Plate
ASTM B168 617 Inconel Alloy Metal Sheet ASTM B168 617 Inconel Alloy Polished Texture Sheet
ASTM B168 617 Inconel Alloy Cut to Size ASTM B168 617 Inconel Alloy Circle
ASTM B168 617 Inconel Alloy Discs ASTM B168 617 Inconel Alloy Blank
ASTM B168 617 Inconel Alloy Shims ASTM B168 617 Inconel Alloy Polished Plates
ASTM B168 617 Inconel Alloy Coils ASTM B168 617 Inconel Alloy Foils
ASTM B168 617 Inconel Alloy Hot Rolled Plates ASTM B168 617 Inconel Alloy Cold Rolled Plates
ASTM B168 617 Inconel Alloy Strips ASTM B168 617 Inconel Alloy Roof Sheets

​

ASTM B168 617 INCONEL ALLOY SHEETS & PLATES EQUIVALENT GRADES

STANDARD WERKSTOFF NR. UNS
Inconel 617 2.4663 N06617

GRADE 617 INCONEL ALLOY SHEETS & PLATES CHEMICAL COMPOSITION

Grade C Mn S Si Cr Mo Ni Cu Ti Al B Co Fe
Inconel 617 0.05-0.15 1.0 Max 0.015 Max 1.0 Max 20.0-24.0 8.0-10.0 44.5 Min 0.5 Max 0.6 Max 0.8-1.5 0.006 Max 10.0-15.0 3.0 Max

ASME SB168 INCONEL ALLOY 617 SHEETS & PLATES MECHANICAL PROPERTIES

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
Inconel 617 8.1 g/cm3 1411 °C (2571 °F) Psi – 80,000 , MPa – 550 Psi – 30,000 , MPa – 205 30 %

EN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 PlateEN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 PlateEN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 PlateEN 2.4663 Nickel Alloy Plate 4ft*8ft 5ft*20ft Cold Rolled Hot Rolled Alloy 617 Plate
