UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft
Specifications
Brand Name :
DELTA
Model Number :
UNS N06625
Certification :
ISO
Place of Origin :
China
MOQ :
10 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Plate
Grade :
hastelloy C276
Diameter :
10 - 350mm
Length :
custom cutting any length as request
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
black, bright
Description

UNS N06625 Nickel Alloy Bars Diameter 10 - 300mm Hot Rolled Poilsihed Shaft

Products Specification

Inconel 625 ASTM Standard for Bar ASTM B446, ASME SB 446, AMS 5666
Specifications ISO 9723, ISO 9724, ISO 9725, VdTüV 499, BS3076NA21, EN 10095, DIN 17752, DIN 17753, DIN 17754; DIN, EN, ASTM, JIS, ASME, BS, AISI
625 Inconel Round Bars size Diameter: 3-~800mm
Inconel 625 Flat Bars size Thickness: 2 -100mm
Width: 10 to 500mm
Inconel 625 Angle Bars size 3mm*20mm*20mm~12mm*100mm*100mm
Inconel 625 Channel Bars 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness
Alloy 625 Rectangular Bars Section 3.0 to 12.0mm thickness
Inconel 625 Billet Size 1/2 to 495mm Diameter
Inconel 625 Rectangle Bar Size 33 x 30mm to 295 x 1066mm
Inconel 625 Hex Bar size 2-100mm A/F
Inconel 625 Hollow Bars 32mm OD x 16mm ID to 250mm OD x 200mm ID)
Diameter 20mm, 30mm, 50mm, 80mm, 100mm, 150mm, 200mm, 500mm
Length 1m-12m or as required
Tolerance H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Finish hot rolled annealed, peeled, Bright, hot-worked and cold-worked rod and bar, centreless ground, Centreless Ground and Black, Polish, Cold Rolled (CR), hot rolled ( R), smooth turned, Cold (bright) drawn, Grinding, slit rolled edge, Rough Turned.
Surface Hot Rolled Pickled, Bright, Sand Blasting Finished, Cold Drawn, Hairline,Polished
Condition Hardened & tempered, annealed
Technique Cold Drawn, Hot Rolled, Forged Round Bars, Cold Rolled, Rod
Processing Bars cutting to 650mm
Form Rod, Round, Channel Bars, T-Bars, Flat Bars, Precision Ground Bars, Blocks, Square, Round Rod, Triangle, Hollow, Rectangle, Threaded, Hex (A/F), Profiles, Half Round Bars, Ingot, Billet, I/H Bars, Forging etc.

Inconel 625 bar introduction
Inconel 625 is a nickel-based superalloy composed mainly of nickel, chromium, molybdenum and niobium, with excellent corrosion resistance, high temperature strength and oxidation resistance. It performs well in extreme environments and is widely used in aerospace, chemical, ocean engineering and other fields.

specification of Inconel 625 Round Bars
Inconel 625 bars come in a variety of sizes, from 6mm to 300mm in diameter and usually 3 or 6 meters in length, and can also be customized according to requirements.

Standard of Inconel 625 Round Bars

  • Inconel 625 bars are produced and tested according to the following standards:
  • ASTM B446: Standard Specification for Nickel Alloy Bars, Wires, and profiles.
  • AMS 5666: Specification for Aerospace materials, applicable to superalloy bars.
  • DIN 17752: German standard for nickel and nickel alloy bars.

EQUIVALENT GRADES OF INCONEL 625 ROUND BARS

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
Inconel 625 2.4856 N06625 NCF 625 NA 21 ХН75МБТЮ NC22DNB4M NiCr22Mo9Nb

CHEMICAL COMPOSITION OF INCONEL 625 ROUND BARS

Grade C Mn Si S Cu Fe Ni Cr
Inconel 625 0.10 max 0.50 max 0.50 max 0.015 max – 5.0 max 58.0 min 20.0 – 23.0

Peculiarity of Inconel 625 Round Bars

  • Corrosion resistance: Excellent performance in both oxidizing and reducing environments, especially in acidic and chloride environments.
  • High temperature strength: still maintain high strength at high temperature, suitable for high temperature environment.
  • Oxidation resistance: It has good antioxidant properties at high temperatures.
  • Fatigue strength: High fatigue strength, suitable for cyclic load.
  • Machinability: It can be formed by a variety of processing methods, but pay attention to its high strength and hardness.

Application of Inconel 625 Round Bars
Inconel 625 bars are widely used in the following fields:

  • Aerospace: Used in engine components, combustion chambers and turbine blades.
  • Chemical: For the manufacture of corrosion resistant reactors, heat exchangers and pipes.
  • Marine engineering: Used in seawater treatment equipment and Marine components.
  • Nuclear industry: Components used in nuclear reactors.
  • Oil and gas: Used for downhole tools and pipeline systems.

Inconel 625 bars are widely used in many industrial fields due to their excellent corrosion resistance, high temperature strength and oxidation resistance. Its specifications and standards are diverse, and suitable products can be selected according to specific needs.
