ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
Specifications
Brand Name :
DELTA
Model Number :
201 304 316L 321 310S 314 347 2205 2507 904L.etc
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
2400 - 3500 USD/Ton
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
BA Stainless Steel Pipe
Grade :
304 316L 321 2205 310S 904L.etc
Standard :
ASTM GB EN
Length :
6m or as request
Diameter :
6 - 219mm or as clients request
Wall thickness :
0.4 - 8.0mm
Type :
seamless pipe
Service :
cutting
Other Shape :
square, rectangle
Description

ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area

Products Specification

Standard ASTM A213, ASTM A269, ASME SA213, ASME SA269
Pipe Type Bright Annealed Stainless Steel Tubing
Grades 304, 304L, 316, 316L, 321, 310S, 2205, 2507
Dimensions Outer Diameter (OD): 1.00 mm to 76.2 mm
Wall Thickness 0.2 mm to 6.0 mm
Length Up to 12 meters (custom lengths available upon request)
Manufacturing Process Cold Drawn, Bright Annealed, Seamless
Material Surface Finish Bright Annealed (BA), Mirror Polished, No. 4 Finish
End Type Plain End (PE), Beveled End (BE), Threaded End (TE)
Certifications ISO 9001, EN 10204 3.1 / 3.2, PED, ASME

Bright Annealed Stainless Steel 316L Pipe, SS 316L Bright Annealed Seamless Pipes, SS 316L BA Pipes, Stainless Steel 316L Bright Annealed Welded Tube Distributors, SS 316L Bright Annealed Tubing, SS UNS S31603 Bright Annealed Tube Exporter , SUS 316L BA Seamless Tube, AISI 316L Steel BA Welded Pipe Manufacturer, 316L Stainless Steel Bright Annealing Seamless Pipe, DIN 1.4404 / 1.4435 BA Tubes Supplier

Stainless Steel 316L BA Pipe, SS 1.4404 / 1.4435 Bright Annealed Pipe, SS 316L Bright Annealed Seamless Tube Traders , SS 316L BA Seamless Pipe, Stainless Steel S31603 BA Tubing, ASTM A312 Stainless Steel 316L Bright Annealed Pipe, ASTM A249/ A269 / A270 Stainless Steel 316L Bright Annealed Tube, Stainless Steel AISI 316L Bright Annealing Welded Pipe Stockists , Stainless Steel 316L Bright Annealed Piping Stockholders, Bright Annealed SS 316L Tube Dealers, 316L SS BA Welded Tube Manufacturers

SS 316L Bright Annealed Pipe and Tube Equivalent Grades

STANDARD UNS WERKSTOFF NR. AFNOR EN JIS BS GOST
SS 316L S31603 1.4404 / 1.4435 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2

Stainless Steel 316L BA Pipes and Tubes Chemical Composition

Grade C Mn Si P S Cr Mo Ni Fe
SS 316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 - 18.00 2.00 - 3.00 10.00 - 14.00 68.89 min

Bright Annealed SS 316L Pipe and Tubing Mechanical Properties

Tensile Strength Yield Strength (0.2%Offset) Elongation Hardness
Rockwell B (HR B) max Brinell (HB) max
Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 % 95 217

Stainless Steel Tube Bright Annealing Marking & Packing

  • Marking according to MPS and Standard
  • Stainless Steel Tubes Ends with Caps according to PO
  • In Seaworthy Wooden Cases With Plastic Paper protect
  • In Plywood Cases With Plastic Paper Protect(Recommend, All Plywood Cases made by ourselves with lower cost.)
  • Steel Racks Package
  • Hexagonal packing in Bundles

ASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food AreaASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food AreaASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food AreaASTM A269 TP316L Stainless Steel Pipe Tube Bright Annealed for Medical and Food Area
