Specifications
Brand Name :
DELTA
Model Number :
Inconel 600
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Plate
Grade :
UNS N06600 / Inconel 600
Thickness :
0.5 - 16.0mm
Width :
1000mm 1219mm 1500mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1
Description

Thickness 1.0mm 1.2mm 1.5mm 2.0mm 2.5mm 3.0mm Inconel 600 /Alloy 600 Sheet / Plate/ Coil

Products Specification

Product Name UNS 06600 / Inconel 600 Nickel Alloy Plate

Standard

 ASTM EN DIN GB JIS
Thickness

Cold Rolled: 0.6mm,0.8mm,1.0mm,1.2mm,1.5mm,2.0mm,2.5mm,3.0mm

Hot Rolled:4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm

Forged : 20 - 200mm custom any size as request
Standard Size

Cold rolled Sheet 1219*2438mm

Hot rolled Plates 1500*6000mm
Main Grade 600,601,625,718,800,800H,800HT,926,C276,C4,Monel400 K500 904L 254SMO 654SO 317L.etc
Service Laser Cutting any size as request
Other Products Coil, Sheet, Plate, Wire, Round Bar, Square Bar,Pipe,Tube.etc

Inconel 600 Plate or as also referred to by its trade name UNS N06600 is a non-magnetic, highly corrosion resistant nickel based alloy. Reckoned as a conventional engineering grade alloy, Inconel is a good fit for use across a wide temperature range.Inconel 600 is a solution-hardened nickel-chromium alloy. The non-magnetic Inconel 600 Plate is highly resistant to corrosion and oxidation across different stress-induced environments. The superior concentration of nickel in the Inconel Alloy 600 Plate gives these modules exceptional resistance against chloride stress-corrosion cracking. The versatile grade of alloys of the Inconel 600 sheet is designed to withstand temperature range from cryogenic up to 1093 degrees C. These sheets are easily machinable and can be welded readily.

What Properties of Alloy 600 make it Suitable for chemical and food processing

Alloy 600 Plate is designed with a superior concentration of nickel and chromium, giving these modules enhanced corrosion resistance properties. These high-strength modules have excellent resistance against heat in high-temperature systems up to 2100 degrees F. This coupled with their excellent performance in cryogenic temperatures, makes them a good choice in the food and chemical processing industry.

What is best Inconel 600 temperature range and its Density?

Inconel 600 Plate is a solution-hardened module designed for optimum strength and performance. The Inconel 600 temperature range starts from as low as sub-zero/cryogenic temperatures and goes as 1093 degrees C in different environments. Inconel 600 Density is 8.47 g/cc in metric weight.

Inconel 600 Vs 625

  • Inconel 600 plate is designed with a chemical concentration of 72% nickel with 14% chromium. A 625 Inconel grade is designed with a chemical composition of 58% nickel, 23% chromium, and 10% of molybdenum. The superior concentration gives the 625 grade higher corrosion resistance properties.
  • Inconel 625 plate possesses better strength compared to the 600 Inconel grade.
  • The melting range of the 600 grade is higher than Inconel 625 components.

What is ASTM B168?

Usually, components such as plates, sheets, and strips produced from nickel based alloys such as Alloy 600 are made in accordance with ASTM B168. The products made under this particular specification are to be first sampled and prepared, following which they are to be tested for their conformance to not only their chemistry requirements, but also their mechanical as well as their dimensional requirements. In addition to this, the UNS No 6600 plates are also tested to check if they conform to their grain size requirements


ASTM B168 covers the standard specification of

  • Nickel- Chromium-Molybdenum-Copper Alloy of (UNS N06235) Sheet, Plate, and Strip
  • UNS NO6699 Nickel, chromium, and aluminum alloys
  • Nickel- Chromium-Iron Alloys of UNS N06600, N06603, N06601, N06693, N06690, N06045, N06025, and N06696)
  • (UNS N06674) Nickel- Iron-Chromium-Tungsten Alloy of
  • (UNS N06617) Nickel- Chromium-Cobalt-Molybdenum Alloy

Inconel 600 / UNS N06600 Application

  • Nuclear waste reprocessing equipment
  • Sour gas production tubes
  • Jet Engine exhaust systems
  • Aerospace equipment
  • Moto exhaust systems
  • Chimney Linings
  • Chemical Processing

Typical Mechanical Property Ranges Of UNS N06600 Plate

Element Density Melting Point Yield Strength (0.2%Offset) Elongation Tensile Strength
Inconel 600 Plate 8.47 g/cm3 1413 °C (2580 °F) Psi – 45,000 , MPa – 310 40 % Psi – 95,000 , MPa – 655

Chemical Compatibility Chart Of Nickel Alloy 600 Plate

Grade Fe Cu Si S Mn Cr C Ni
Inconel 600 Plate 6.00 – 10.00 0.50 max 0.50 max 0.015max 1.00 max 14.00 to 17.00 0.15 max 72.00 min

ASTM B168 Alloy 600 sheet Equivalent Properties

STANDARD AFNOR WNR Material Number UNS BS EN GOST JIS
Inconel 600 Plate NC15FE11M 2.4816 N06600 NA 13 NiCr15Fe МНЖМц 28-2,5-1,5 NCF 600
