Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
Specifications
Brand Name :
DELTA
Model Number :
Inconel 600
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
40-45 USD/Kg
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
3 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
Nickel Alloy Plate
Grade :
UNS N06600 / Inconel 600
Thickness :
0.5 - 16.0mm
Width :
1000mm 1219mm 1500mm
Standard :
ASTM EN
Service :
Cutting
Loading Port :
Shanghai Port
Surface :
2B NO.1
Description

Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy

Products Specification

Product Name UNS 06600 / Inconel 600 Nickel Alloy Plate

Standard

 ASTM EN DIN GB JIS
Thickness

Cold Rolled: 0.6mm,0.8mm,1.0mm,1.2mm,1.5mm,2.0mm,2.5mm,3.0mm

Hot Rolled:4.0mm,5.0mm,6.0mm,8.0mm,10.0mm,12.0mm,14.0mm,16.0mm,20.0mm

Forged : 20 - 200mm custom any size as request
Standard Size

Cold rolled Sheet 1219*2438mm

Hot rolled Plates 1500*6000mm
Main Grade 600,601,625,718,800,800H,800HT,926,C276,C4,Monel400 K500 904L 254SMO 654SO 317L.etc
Service Laser Cutting any size as request
Other Products Coil, Sheet, Plate, Wire, Round Bar, Square Bar,Pipe,Tube.etc

Inconel 600 is a solid solution strengthened alloy grade. The Inconel 600 Plate has primary constituents of nickel, chromium, and iron alloys. These plates have excellent resistance to corrosive media across harsh environments. An Inconel Alloy 600 Plate is immune against chloride ion stress corrosion cracking in both high and cryogenic temperatures. The robust inconel 600 chequered Plate has an aesthetical outlook and outstanding strength. The plates showcase good weldability in wide temperature ranges.

The plates can be processed in either hot or cold rolling procedures. A DIN 17742 Hot Rolled Plate is produced at high temperatures till it reaches its recrystallization limit. These plates have excellent ductility and can be easily worked with. The AMS 5540 Cold Rolled Plate is further rolled after the hot rolling process. These plates can be strengthened or their surface finish enhanced to give desired specifications. Inconel 600 Plate Suppliers can also be solution annealed and later air cooled. These plates are available in a range of sizes and specifications as per project needs. The Inconel 600 Plate Hs Code is 7506.

Alloy 600 Plate Thickness
Cold rolled Inconel 600 thin plate 0.2-4mm
Hot rolled 600 Inconel medium plate 4-20mm
Hot rolled ASTM B 168 Inconel 600 thick plate 20-60mm
Hot rolled Inconel Werkstoff No 2.4816 extra thick plate 60-115mm

Nickel alloy 600 600 coil chemical composition

Grade Mn C Si S Fe Cu Ni Cr
Inconel 600 1.00 maximum 0.15 maximum 0.50 maximum 0.015maximum 6.00 – 10.00 0.50 maximum 72.00 minimum 14.00 – 17.00

Equivalent grades of Alloy 600 plate

STANDARD UNS WERKSTOFF NR. JIS BS AFNOR GOST EN
Inconel 600 N06600 2.4816 NCF 600 NA 13 NC15FE11M МНЖМц 28-2,5-1,5 NiCr15Fe

What Are the Features of Nickel Alloy 600 Plate
  • Corrosion resistance
  • Heat resistance
  • High strength
  • Oxidation resistance
  • Non-magnetic
Applications of Nickel 600 Plate
  • Synthetic fiber
  • Water waste projects
  • Marine industry
  • Fluid piping
  • Power plants
  • Petrochemical industry
  • Chemical industry
  • Heat exchanger
  • Pharmaceutical industry

Inconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel AlloyInconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel AlloyInconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel AlloyInconel 600 Plate / Sheet / Coil / Strips ASTM B168 EN 2.4816 Alloy 600 Nickel Alloy
