Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
Specifications
Brand Name :
DELTA
Model Number :
201 304 316L 321 310S 314 347 2205 2507 904L.etc
Certification :
ISO
Place of Origin :
China
MOQ :
500 kgs
Price :
2400 - 3500 USD/Ton
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
10 Ton per week
Delivery Time :
5 - 12 days based on the quantity
Packaging Details :
standard packing for export
Products :
BA Stainless Steel Pipe
Grade :
304 316L 321 2205 310S 904L.etc
Standard :
ASTM GB EN
Length :
6m or as request
Diameter :
6 - 219mm or as clients request
Wall thickness :
0.4 - 8.0mm
Type :
seamless pipe
Service :
cutting
Other Shape :
square, rectangle
Description

Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe


Products Specification

Standard ASTM A213, ASTM A269, ASME SA213, ASME SA269
Pipe Type Bright Annealed Stainless Steel Tubing
Grades 304, 304L, 316, 316L, 321, 310S, 2205, 2507
Dimensions Outer Diameter (OD): 1.00 mm to 76.2 mm
Wall Thickness 0.2 mm to 6.0 mm
Length Up to 12 meters (custom lengths available upon request)
Manufacturing Process Cold Drawn, Bright Annealed, Seamless
Material Surface Finish Bright Annealed (BA), Mirror Polished, No. 4 Finish
End Type Plain End (PE), Beveled End (BE), Threaded End (TE)
Certifications ISO 9001, EN 10204 3.1 / 3.2, PED, ASME

High purity ba/ep tubing Pipe, length 6 meters

  • Size:6.35*0.89mm,6.35*1.00mm,9.53*0.89mm,9.53*1.00mm,12.7*0.89mm,12.7*1.24mm,12.7*1.65mm,19.05*1.24mm,19.05*1.65mm,25.4*1.65mm,38.1*1.65mm,50.8*1.65mm,63.5*1.65mm
  • Standard Length:4m 6m
Specifications:
Imperial size Metric size
OD
inch		 WT
inch		 OD
mm		 WT
mm
1/8 (0.125) 0.028 3.18 0.71
0.035 3.18 0.89
3/16 (0.188) 0.028 4.76 0.71
0.035 4.76 0.89
0.049 4.76 1.24
1/4 (0.250) 0.035 6.35 0.89
0.049 6.35 1.24
0.065 6.35 1.65
0.083 6.35 2.11
3/8 (0.375) 0.035 9.53 0.89
0.049 9.53 1.24
0.065 9.53 1.65
0.083 9.53 2.11
1/2 (0.500) 0.035 12.7 0.89
0.049 12.7 1.24
0.065 12.7 1.65
0.083 12.7 2.11

Tubing length up to 32,808 feet (10,000 m) For control line, chemical injection line

Available materials

  • Austenitic: Stainless steel 316L, Stainless steel 304L,
  • Stainless steel 321
  • Duplex: S31803, S32205
  • Super Duplex: S32750
  • Nickel alloy: N06625, N08825
  • Tolerance:±0.05mm
  • Dimension Range of Tubing
  • Outside Diameter: 1/8" – 1" (3.175 – 25.4 mm)

Dimension Tolerance


ASTM A269 / ASME SA269
Size OD Tolerance OD Wall thickness

≤1/2"
(≤12.7 mm)

1/2
(≤12.7≤25.4)

±0.005"
(±0.13 mm)

±0.005"
(±0.13 mm)

±15%
±10%

±15%
±10%

Features:

1. To decrease welds is to improve safety.

2. Coiled Stainless Steel Tubing doesn’t need welds, so can save users more construction time than using traditional strength tubing.

3. Coiled Stainless Steel Tubing is pliant which helps to decrease welding spatters and keep material clean.

4. Coiled Stainless Steel Tubing is seamless, and all have passed pressure test which reduce the risk of leakage.

5. It’s easy to pack, facilitates storage and shipping.

6. Seamless coil tubing reduce scraps.

Bright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA PipeBright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA PipeBright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA PipeBright Annealed Seamless BA Stainless Steel Pipe TP316L Small Diameter BA Pipe
