304 / 316 Stainless Steel Cable Trellis , Stainless Steel Green Wall Mesh
304 / 316 Stainless Steel Cable Trellis , Stainless Steel Green Wall Mesh
304 / 316 Stainless Steel Cable Trellis , Stainless Steel Green Wall Mesh
304 / 316 Stainless Steel Cable Trellis , Stainless Steel Green Wall Mesh
Specifications
Brand Name :
wanchi
Model Number :
CT-006
Certification :
SGS ISO9001
Place of Origin :
Hebei
MOQ :
50 square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
500+square meter+per week
Delivery Time :
5-8 work days
Packaging Details :
PP film inside and wooden case outside
Material :
Stainless steel wire 304 or 316
Color :
Silver,black,etc
Rope Diameter :
1.2mm-3.2mm
Aperture :
20mm-200mm
Mesh Type :
knotted
Mesh Size :
Custom-made
Description

304 Or 316 Material Stainless Steel Cable Trellis, Green Wall Mesh

1. Material: Stainless steel wire SUS304, SUS304L, SUS316 or SUS316L

2. Feature: Acid-resisting, alkalinity-resisting, heat-resisting, wear-resisting and oxidize-resisting

3. Weaving patterns: Plain weave and twill weave, Dutch weave

4. Process: compiled by a special process, metal lines with the unique flexibility and brightness, deeply museum, exhibition hall and other brand personality decoration of all ages.

5. Feature:nonflammable, high strength, durable, easy maintenance, functional and decorative effect vivid, strong, and to good effect on the building structure protection. The installation is simple and fast, shape chic and elegant.

6. Applications:curtains, screens for dining hall, isolation in hotels, ceiling decoration, animal containment an stair channel high-grade interior decoration of hotels, etc

Type Breaking load ( KN ) Wire Dia.(MM) Mesh Opening (MM)
7 X 19 7.38 3.2

120x120,102x102,

90x90,76x76,51x51
7 x 19 4.18 2.4 102x102, 90x90,76x76,51x51
7 x 7 3.17 2.0 76x76,60x60,51x51,38x38
7 x 7 2.17 1.6

76x76,51x51,38x38,

30x30,25.4x25.4
7 x 7 1.22 1.2

51x51, 38x38,30x30

25.4x25.4,20x20

1. Knotted mesh is a kind of plain weave, each warp wire rope crosses alternately above and below each weft wire rope. Warp and weft wire ropes generally have the same diameter.
2.Ferruled mesh is of the same physical properties with the knotted mesh, the only difference is in the combination style, the stainless wire rope are combined by the ferrules which are made of the same grade stainless steel.
