316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
Specifications
Brand Name :
WANCHI METAL
Model Number :
WT-012
Certification :
ISO9001
Place of Origin :
Hebei
MOQ :
100 rolls
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 rolls per week
Delivery Time :
7 days after payment received
Packaging Details :
PP film inside and wooden case outside
Technique :
Welded Mesh
Type :
Weave Wire Mesh
Material :
Stainless Steel Wire,316,304
Application :
Woven Wire Mesh,Decorative wire mesh,Protecting Mesh
Weave style :
Plain Weave
Product name :
Metal woven mesh,Stainless Steel Architectural Woven Wire Mesh
Wire diameter :
1-6mm
Color :
Silver,black
Length :
30m/roll 50m/roll or as required
Width :
0.5m-3m or customized
Feature :
Anti-corrosion,Beautiful,Heat Resisting,Flexibility
Sample :
Avaliable
Name :
Welded Wire Mesh Fence,304 316 20Mesh Plain Woven Stainless Steel Wire Mesh
Description

Stainless steel rope mesh ,also called SS cable mesh, made form high quality stainless steel wire rope, with the features ofextremely anti-corrosion and esistant to UV rays, has a long lifespan in the harsh environments.

Product Name
Stainless steel wire rope mesh(stainless steel cable mesh)
Certifacates
CE and ROHS Certificates
Material
AISI 304 or AISI 316
Wire Diameter
1mm-5mm, the common diameter:1.5mm,2.0mm,3.0mm
Wire Structure
7*7 or 7*19
Opening Hole Size
From10*10mm to 300*300mm,the common size:40*70mm 50*90mm 60*104mm 80*140mm.
Woven Type
Ferruled type and Knotted type

1. Knotted mesh is a kind of plain weave, each warp wire rope crosses alternately above and below each weft wire rope. Warp and weft wire ropes generally have the same diameter.
2.Ferruled mesh is of the same physical properties with the knotted mesh, the only difference is in the combination style, the stainless wire rope are combined by the ferrules which are made of the same grade stainless steel.

Model No.
Material Group
Wire rope
construction
Wire rope dia.
Mesh Aperture
Weight
mm
inch
mm
inch
kg/m2
LE-2476
SS304/316
7 x 7
2.4
3/32"
76X76
3" x 3"
0.72
LE-2460
SS304/316
7 x 7
2.4
3/32"
60X60
2.4" x 2.4"
0.87
LE-2451
SS304/316
7 x 7
2.4
3/32"
51X51
2" x 2"
1.02
LE-2076
SS304/316
7 x 7
2.0
5/64"
76X76
3" x 3"
0.5
LE-2060
SS304/316
7 x 7
2.0
5/64"
60X60
2.4" x 2.4"
0.76
LE-2051
SS304/316
7 x 7
2.0
5/64"
51X51
2" x 2"
0.8
LE-2038
SS304/316
7 x 7
2.0
5/64"
38X38
1.5 x 1.5
1.1
LE-1651
SS304/316
7 x 7
1.6
1/16"
51X51
2" x 2"
0.5
LE-1638
SS304/316
7 x 7
1.6
1/16"
38X38
1.5 x 1.5
0.65
LE-1630
SS304/316
7 x 7
1.6
1/16"
30X30
1.2" x 1.2"
0.9


316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting

316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting

All the Specifications could be Customized!

Installation Accessories

316 Ferrule Type Wire Cable Rope Stainless Steel Zoo Mesh For Aviary Net Bird Netting
