Product Description

Application:
Ball valve is well used in food, beverage, chemical and cosmetic industries to control medium flow. The full port design with zero restriction makes it an optimum choice for viscous and particulate liquids.

Working Principle:
Manual ball valve can be operated through actuator(90 degree rotary handle), actuator with the hand is to revolve the axial movement unto 90 degree, so the valve can open or close.
Pneumatic actuator is to covert the axial movement of piston to be 90 degree rotation of valve shaft, so that the valve can be open or close to achieve the requirement of control and open /close for the pipeline system.

Standard Design:
Various standards of ball valves can be provide can be provided to clients: DIN, 3A, SMS, ISO/IDF, BS/RJ, ASME/BPE etc.

Features:
(1) The fluid resistance is small, and the full-diameter ball valve has substantially no flow resistance.
(2) Simple structure, small size and light weight.
(3) Close and reliable. It has two sealing faces, and the sealing surface material of the ball valve is widely used in various plastics, and has good sealing performance and can achieve complete sealing. It has also been widely used in vacuum systems.
(4) It is easy to operate, and it can be opened and closed quickly. It can be rotated by 90° from full opening to full closing, which is convenient for long-distance control.
(5) Convenient maintenance, the ball valve has a simple structure, and the sealing ring is generally active, and it is convenient to disassemble and replace.
(6) When fully open or fully closed, the sealing surface of the ball and the valve seat is isolated from the medium, and when the medium passes, it will not cause erosion of the sealing surface of the valve.
(7) Wide range of applications, from small to a few millimeters, up to a few meters, from high vacuum to high pressure can be applied.
(8) Since the ball valve has wiping property during opening and closing, it can be used in a medium with suspended solid particles.
