Specifications
Brand Name :
BS•EVER
Model Number :
Stainless Steel Twill Weave Wire Mesh
Certification :
ISO 9001:2015
Place of Origin :
CHINA
MOQ :
30 Sq.m
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
300 Sq.m/ Day
Delivery Time :
According to the Quantity Ordered
Packaging Details :
Moisture proof paper & plastic film, Wooden Case or Pallet.
Name :
Stainless Steel Twill Weave Wire Mesh
Mesh :
250-635
Material :
Stainless steel, nickel, Monel metal, phosphor bronze, other metals
Roll Size :
1x30m
Port :
Xingang,Tianjin
Sample :
Free Charged
Description

Bright Raw Edge Stainless Steel Twill Weave Wire Mesh With Mesh 250 - 635 for Filter

The stainless steel wire mesh can be divided into four kinds according to the weaving method,stainless steel plain weave wire mesh, stainless steel twill weave wire mesh,stainless steel plain dutch weave wire mesh, stainless steel twill dutch weave wire mesh.

250 - 635 Mesh Stainless Steel Wire Cloth , Woven Metal Mesh Anti - Corrosion

“Twilled weave” is a weave type in which the warp wires and shute wires pass over two and under two in both directions. This is different from a plain weave, which is when the wires are woven one over and one under. As a result, “twilled weave” is often more pliable than a comparable plain weave wire mesh specification. By and large, twilled weave is often used in filtration applications. The images below illustrate twilled weave, but because twilled weave is usually reserved for fine mesh, identifying a twilled weave usually requires a mesh counter.

250 - 635 Mesh Stainless Steel Wire Cloth , Woven Metal Mesh Anti - Corrosion

Applications
Sizing (screening), separation (filtering), refining, drying, reinforcement, catalysts, conveyors, shielding, and other industrial, mining and agricultural applications

Material:

Stainless steel 201/304/304L/316/316L/310S/321/317L/410S/431/904L, pure nickel, Monel metal, titanium, copper, brass, aluminum alloys,etc.

Twilled Weave (250 to 635 mesh)

Mesh Wire Diameter Opening
mm		 Open Area % Mass (Weight)
kg/m2 stainless steel wire cloth
SWG mm
250 48 0.04 0.062 35.8 0.212
300 48 0.04 0.045 26.8 0.254
325 48・1/2 0.035 0.043 30.5 0.210
350 49 0.03 0.042 33.6 0.167
400 49 0.03 0.034 27.8 0.180
500 50 0.025 0.026 25.8 0.160
635 0.020 0.020 25.0 0.130

250 - 635 Mesh Stainless Steel Wire Cloth , Woven Metal Mesh Anti - Corrosion

250 - 635 Mesh Stainless Steel Wire Cloth , Woven Metal Mesh Anti - Corrosion
