Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
Specifications
Brand Name :
BS•EVER
Model Number :
Stainless Steel Welded Wire Mesh
Certification :
ISO 9001:2015
Place of Origin :
CHINA
MOQ :
30 Sq.m
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
1000 Sq.m/ Day
Delivery Time :
According to the Quantity Ordered
Packaging Details :
Moisture proof paper & plastic film, Wooden Case or Pallet.
Name :
Stainless Steel Welded Wire Mesh
Material :
Stainless Steel Wire, Black Wire Mesh, Galvanized Steel Wire, 316L, ss201 304 316 or 316L wire
Roll Size :
1X30m/Customized
Hole Size :
1/4“ - 4” /Customized
Sample :
Free Charged
Port :
Xingang,Tianjin
Technique :
Welded Mesh, Woven
Type :
Welded Mesh, Weave Wire Mesh, Wire Cloth, Reinforced Mesh
Description

Stainless Steel Welded Wire Mesh With Different Hole Size in Sheet / Roll

Welded wire mesh is constructed with two orthogonal wires that are joined together at their intersections using a resistance welding process to form a grid. The line wires of the grid are guided through the welder using a pattern board. The machine drops cross wires into place and fuses them together to create the two distinctive planes that form welded wire mesh.

Trim and Stub Options
We offers a variety of trim and stub options to suit your needs. Contact one of our knowledgeable sales representatives if you’re not sure which option is best for your project.

Trimmed: Minimum on all four sides approximately 1/16″-1/8″ long. Trimmed flush (no stubs) must be specified when required.
Untrimmed Balanced Stubs: Equal stubs on opposite sides only. Stubs will not exceed opening unless specified.
Balanced Stubs with Edge Wire: Equal stubs on opposite sides with welded edge wire. (Special order only)

Untrimmed Random Stubs: Varies on all four sides. Results from shearing a larger sheet, pieces will not be identical.

Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion ResistantCustom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion ResistantCustom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion ResistantCustom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant

Trimme Untrimmed Balanced Balanced Stubs Random Untrimmed

Materials: Stainless steel,Carbon Steel,Iron Steel,Galvanized,PVC,etc.

Specification List of Welded Wire Mesh
Opening Wire Diameter
In inch In metric unit(mm)
1/4" x 1/4" 6.4mm x 6.4mm 22,23,24
3/8" x 3/8" 10.6mm x 10.6mm 19,20,21,22
1/2" x 1/2" 12.7mm x 12.7mm 16,17,18,19,20,21,22,23
5/8" x 5/8" 16mm x 16mm 18,19,20,21,
3/4" x 3/4" 19.1mm x 19.1mm 16,17,18,19,20,21
1" x 1/2" 25.4mm x 12.7mm 16,17,18,19,20,21
1" x 1" 25.4mmX25.4mm 16,17,18,19,20,21
1-1/2" x 1-1/2" 38mm x 38mm 14,15,16,17,18,19
1" x 2" 25.4mm x 50.8mm 14,15,16
2" x 2" 50.8mm x 50.8mm 12,13,14,15,16
2" x 3" 50mmx70mm 2.0mm,2.5mm,1.65mm
3" x 3" 75mmx75mm 2.67mm,2.41mm,2.11mm,1.83mm,1.65mm
2" x 4" 50mmx100mm 2.11mm,2.5mm
4" x 4" 100mmx100mm 2.0mm,2.5mm
Technical Note:
1, Standard roll length: 30m; width: 0.5m to 1.8m
2, Special sizes available at request
3, Packing: in waterproof paper in rolls. Custom packing available at request.

Custom 1 X 1 Welded Steel Mesh Rolls , Stainless Steel Welded Mesh Corrosion Resistant
