Radial And Axial Loads Stainless Steel Deep Groove Ball Bearings 625zz Anti Rust
Radial And Axial Loads Stainless Steel Deep Groove Ball Bearings 625zz Anti Rust
Radial And Axial Loads Stainless Steel Deep Groove Ball Bearings 625zz Anti Rust
Radial And Axial Loads Stainless Steel Deep Groove Ball Bearings 625zz Anti Rust
Specifications
Brand Name :
Kentie
Model Number :
625ZZ
Certification :
CE/SGS/ISO/Germany Ryan
Place of Origin :
China
MOQ :
100pcs
Price :
US$0.27
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
500,000pcs per month
Delivery Time :
2-3 work days
Packaging Details :
Plastic tube and paper carton
Material :
420 stainless steel
Specification :
5*16*5mm
Dynamic Load Rating :
1.13KN
Static Load Rating :
0.56KN
Speed :
40000rpm
Weight :
0.005kg
Seals type :
Metal Shields
Retainer :
Nylon/steel
OEM :
Availible
Clearance :
C0,C2,C3,C4,C5
Description

Radial And Axial Loads Stainless Steel Deep Groove Ball Bearings 625zz Anti Rust


Product features:
Deep groove geometry for high speeds and supporting both radial and axial loads
Chrome steel for durability and resistance to deformity under heavy loads
Shields on both sides of the bearing to keep lubricant in and contaminants out

Measurements:
Inner Diameter: 5
Outer Diameter: 16
Thickness: 5

Materials:
Bearing Type: Radial Bearing
Product Seal: Two Metal Shields (ZZ)
Ball Material: 420 Stainless Steel
Retainer Material: Metal or High Speed Plastic

Technical Specifications:
Condition: New Inventory From Factory.
Quality Level: ABE-1 or Better
Operating Temperature: Sealed or Metal Shields Ranges: –20 °F to +230°F [–30 °C to +110°C]. The determining factor will be the lube and the seal material.
Raceways: Finely polished superior finish for long life, and low noise.
Lubrication Wide temperature range (-50F to + 300F) High Quality Synthetic Lubricant.

Specifications

Bearing Model S625ZZ bearing
Outer Diameter 16mm
Inner Bore 5mm
Width 5mm
Material Stainless Steel 420
Seals ZZ
Lubrication Grease
Package Plastic tube

Our Advantages

1. Professional Stainless Steel Bearing manufacturer since 1998

2. High quality with ISO standards

3. Low noise, low vibration, smooth rotation

4. High corrosion resistance, 72 hours salt spray test

5. Free OEM

NO d D B Load Rating Steel Ball Chamfer Weight
Bearing No mm inch mm inch mm inch Cr N Cor N Amount Size KG
SS605 5 14 5 1.33 0.505 6 2.381 0.3 0.0045
SS606 6 17 6 2.19 0.865 8 2.381 0.3 0.006
SS607 7 19 6 2.24 0.91 6 3.969 0.3 0.007
SS608 8 22 7 3.35 1.4 7 3.969 0.3 0.015
SS609 9 34 7 3.4 1.45 7 3.369 0.3 0.016
SS6000 10 26 8 4.55 1.96 7 4.763 0.3 0.019
SS6001 12 28 8 5.1 2.39 8 4.763 0.3 0.022
SS6002 15 32 9 5.6 2.84 9 4.763 0.3 0.031
SS6003 17 35 10 6.8 3.35 10 4.763 0.3 0.04
SS6004 20 42 12 9.4 5.05 9 6.35 0.6 0.068
SS6005 25 47 12 10.1 5.85 10 6.35 0.6 0.078
SS6006 30 55 13 13.2 8.3 11 6.747 1 0.11
SS6007 35 62 14 16 0.3 11 7.938 1 0.148
SS6008 40 68 15 16.8 11.5 12 7.938 1 0.185
SS6009 45 75 16 21 15.1 12 9 1 0.23
SS6010 50 80 16 21.8 16.6 13 9 1 0.258
SS6011 55 90 18 28.3 21.2 11 11.1125 1 0.362
SS6012 60 95 18 29.5 23.2 13 11.1125 1 0.385
SS6013 65 100 18 30.5 25.2 13 11.1125 1 0.41
SS6014 70 110 20 38 31 13 12 1 0.575

Detailed Pictures

Radial And Axial Loads Stainless Steel Deep Groove Ball Bearings 625zz Anti Rust
