Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Industrial Sintered Metal Filter Elements 5um 40 Inch Compressor Air Filter Element
Specifications
Brand Name :
XinLi
Model Number :
Sintered Porous
Certification :
ISO9001
Place of Origin :
HeNan
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
8000+Piece+Per Month
Delivery Time :
20-25 Work Days
Packaging Details :
Plastic Bubble Film+Carton+Wooden Box
Micron :
0.25-80um
Working temperature :
-200-900℃
Diameter :
20-300mm and customized size
Filter Rating :
99%
Thickness :
2mm and customized size
Color :
Silver
Length :
10'',20'',30'',50'',and customized size
Material :
316L
Description

Industrial Grade 5um 40Inch 316L Stainless Steel Powder Sintered For Air Compressor

Production Introduction:

The Sintered powde filter cartridge is made of stainless steel powder, after classification, molding, sintered to be the filter cartridge, has uniform aperture and structure, with high porosity and low filtration resistance, it has wonderful filtration effect. Due to the usage of the titanium material, it has perfect chemical stability, which makes it suitable for the filtration of the strong corrosive solvents. It is also can be cleaned repeatedly, which gives it a longer service life.

Specification:

Length:10", 20", 30", 40" etc. other length can be customized as customers require. Diameter:30mm-300mm(or as your request)

Working temperature:-200-900℃

Precision:0.25um-100um

Product Feature:

1. High mechanical strength, with the ability to maintain a steady filter rating under high pressure.

2. Easy to clean with a variety of filter cleaning techniques and reuse.

3. Heat and corrosion resistant.

4. Easy to fabricate, weld, punch, shear, or otherwise form into various parts.

5. Wide range of filter ratings.

Application:

1. Liquid and gas filtration
2. The chemical industry
3. Fluidized beds
4. Chromatography frits
5. Centrifuges
6. Hydraulic filters
7. Sand control screens in oil wells
8. Polymer filtration

Connector Type:

Technical Data:

Filteration Class

Filtering Rating

(um)

Pore Size Max.

(um)

Permeability

10-12m²

Breathability

m3/h.m2.KPa

Thickness

(mm)

Compression

Strength

MPa/ cm²
S9 0.2 2.5 1 3 3.0
S8 0.5 4 3 3 3.0
S7 1.0 6 5 3 3.0
S6 2.5 10 0.09 10 3 3.0
S5 5 15 0.23 40 3 3.0
8 20 0.91 80 3 3.0
S4 10 30 1.81 160 3 3.0
S3 28 60 3.82 350 3 3.0
35 80 7.29 500 3 3.0
S2 40 100 9.43 700 3 3.0
S1 65 160 15.1 1000 3 3.0
