20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
20 Micron 316L Sintered Fiber Felt Filtration Mesh Sheet 0.3-0.6mm Thickness
Specifications
Brand Name :
XinLi
Model Number :
XLSFF
Certification :
ISO9001
Place of Origin :
HeNan
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
5000 Piece Per Month
Delivery Time :
15Days
Packaging Details :
Air bubble foam + wooden box , or as the clients requirement
Material :
100% Stainless Steel 316L
Product name :
20 Micron 316L Sintered Metal Fiber Felt Mesh Sheet For Filtration
Shape :
Sheet
Thickness :
0.3-0.6mm
Feature :
High dirt holding capacity
Working Temperature :
480℃
Filtration Rate :
20um
Technology :
Sintered
Description

20 Micron 316L Sintered Metal Fiber Felt Mesh Sheet For Filtration

Product Introduction:

Metal sintered fiber felt is made of extremely fine steel fiber (micron grade) by sintering in high temperature after special non-woven matching and laying with the pore gradient formed by layers of different pore sizes.

Sintered non-woven fiber felt feature:

1. High dirt holding capacity, high filtering accuracy, long replacement period;
2. High porosity ,excellent permeability,low pressure drop and large flow.
3. Corrosion and high temperature resistance of acid, alkali and organic solvent,pharmaceutical etc. Resistance , can be used under 480℃ for long time.
4. Easy to be processed and welded.
5. Special specifications are on request.

Standard Material SS316L
Micron 5-80um
Standard Size 500*1000mm, 600*1200mm, 1000*1000mm or Required
Thickness 0.3-0.6mm
Shape Round , Square , Ring , Cartridge,And Customize Size
Operating Temperature Under 480℃ for long time

Technical parameters

Type:

Application:

Polymer filtration, Petrochemical, High temperature gas dedusting, Oil refining process filtration,Adhesive filtration, Pre-filtration of ultrafilter, Vacuum pump protection filter, Filter membrane support body, Catalyst carrier, Automobile airbag, Aircraft ship and other fuel filtration,Hydraulic system filtration,etc.
