Specifications
Brand Name :
Xinli
Model Number :
XLCC
Certification :
ISO9001
Place of Origin :
Henan
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
70 pcs/2 month
Delivery Time :
20 working days
Packaging Details :
Air bubble foam + wooden case
Filtration media :
5-layer mesh
Product name :
Standard Sintered Mesh Filter disc Used For Chromatographic Column Equipment
Application :
Pharmaceutical
Material :
SS304/316L
Thickness :
1.7mm
Color :
Silver
Pore size :
1~200micron
After-sales service provided :
Online support
Description

Standard Sintered Mesh Filter disc Used For Chromatographic Column Equipment

Product description:
The application of the standard five-layer sintered mesh on the chromatography equipment is very mature, and the disc is more directly fixed to the flange and sealed with gasket,there are also direct sintered mesh welded on flanges, then fixed.

Technical parameters:

Name Chromatographic Column Filter Disc
Material 304 or 316L stainless steel
Filter rating 150mesh,200mesh,400mesh or customized
Size and Shape Standard
Standard thickness 1.7mm
Temperature 600℃
Connectors Flange(standard or customized)

Product role:

The filter disc plays an important role in supporting the fine particles and the smooth passage of liquid materials which need to be purified.

in the chromatography equipment, equipped with silica gel, activated carbon, alumina, ion exchange resin and ion exchange fiber powder particles, used for purification of liquid materials, or adsorption useless and harmful ingredients, or adsorption useful ingredients, finally achieve the purpose of purification.

Application:

Widely used in pharmaceutical, food industry etc.
