0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
Specifications
Brand Name :
BAOSTEEL ANSTEEL SHOUSTEEL
Model Number :
0Cr17Ni7Al (17-7PH/S17700)
Certification :
ISO SGS
Place of Origin :
China(mainland)
MOQ :
500KGS
Price :
US $7.77-10.77 / Kilogram
Supply Ability :
500 ton/month
Delivery Time :
5-8 working days
Packaging Details :
standard export seaworthy packing or as required
name :
stainless steel plate
length :
1800mm-12000mm
Application :
Coiled Spring and Leaf Spring
Certificate :
Mill Test Certificate
Similar Grade :
AISI 17-7P,SUS 631,S17700
Surface Treatment :
Nature Bright Or P&O
Description

0Cr17Ni7Al (17-7PH/S17700) Precipitation Hardening Stainless Steel Sheet

Product Description

Chemical composition(mass fraction)(wt.%) of the 0Cr17Ni7Al

Elements Min.(≥) Max.(≤)
C - 0.09
Si - 1.00
Mn - 1.00
P - 0.035
S - 0.030
Ni 6.50 7.75
Cr 16.00 18.00
Cu - 0.50
Al 0.75 1.50

Application

17-7PH S17700 0Cr17Ni7Al Mainly Applicaiton

Offshore platforms, helicopter deck, other platforms, food industry, pulp and paper, aerospace (turbine blades), mechanical parts, barrels of nuclear waste 17-4PH alloy is a precipitation hardening martensitic stainless steel. 17-4PH alloy is a precipitation of copper, niobium / columbium constituted hardening martensitic stainless steel. This level has high strength, hardness (up to 300 & ordm; C / 572 & ordm; F)and anti-corrosion properties. After heat treatment, the mechanical properties of products more perfect,can reach up to 1100-1300 mpa (160-190 ksi) of compressive strength. This level can not be used above300 & ordm; C (572 & ordm; F) or under very low temperatures, its atmosphere and dilute acid or salt has good corrosion resistance, corrosion resistance and its 304 and 430 the same.

FAQ

1 Q:Do you accept the sample order?
A: Yes, we accept the sample order. If you order the small piece in stock, it is free.

But we do not pay for the freight cost.


2 Q: How long is your delivery time?
A: Usually 45 to 60 days after your down payment, it also according to the material requirement
and the quantity you ordered.

3 Q: What is your terms of payment.
A: Payment less or equal 10000USD,100% T/T in advance. Payment more than 10000USD,
30% T/T in advance, balance before shippment.


5.Q:What is your working time?
A:Monday-Friday : 8:30AM-17:00PM (Beijing time, GMT+08.00)
While by whatsapp you can contact me anytime if I am awake up.

Contact Us

Why US

1) Honest: we will strictly adhere to the contract, you will get the exact quality and quantity from us. We never
receive any complain from the clients for the quantity and weight.
2) Competitive price with shipment in time.
3) Strictly control on the quality.
4) More than 16 years experience in the export.
5) Best service after sale: We will be responsible for any disputes and problems occured after shipment, we assure you that we will be responsible to the end once our service starts.

17-7PH Physical Properties

  • Melting Range: 2560-2625°F (1404-1440°C)
  • Density: 0.2820 lb/in³

Mean Coefficient of Thermal Expansion

(Annealed Condition)
Temperature Range Mean Coefficient of Thermal Expansion
°C °F μm/m°C in/in/°F·10⁶
21-93 70-200 15.3 8.5
21-204 70-400 16.2 9.0
21-316 70-600 17.1 9.5
21-427 70-800 17.3 9.6

Thermal Conductivity (TH 1050 Condition)
Temperature Range Coefficients
°C °F W/m·K Btu/(hr/ft²/in/°F)
149 300 16.87 117
260 500 18.46 128
449 840 21.05 146
482 900 21.05 146

Magnetic Permeability (Annealed Condition)
Oersteds AT/m μ
25 1989 1.4 - 3.4
50 3878 1.4 - 3.6
100 7956 1.4 - 3.5
200 15.912 1.4 - 3.2
max max 1.4 - 3.6

Electrical Resistivity (Annealed Condition)

  • Microhm-cm: 80

Mechanical Properties and Yield Strength of 17-7PH

Room Temperatures (Annealed)

  • Ultimate Tensile Strength psi (MPa): 130,000 (896)
  • 0.2% Tensile Yield Strength psi (MPa): 40,000 (276)
  • Elongation % in 2" (50mm): 35
  • Hardness Rockwell: B85

0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened0Cr17Ni7Al 17-7PH/S17700 Stainless Steel Sheet Plate Bright Precipitation Hardening Sediment Hardened
