Specifications
Brand Name :
TISCO,BAO STEEL
Model Number :
Nimonic 80A
Certification :
SGS,ISO
Place of Origin :
CHINA
MOQ :
100 kgs
Price :
10-50 USD/KG
Payment Terms :
T/T
Supply Ability :
1500 Tons every month
Delivery Time :
7 days
Packaging Details :
Export packing
name :
hastelloy plate
type :
sheet / plate
Application :
Chemical industrial
Thickness :
0.03 - 1.00 mm
Width :
3.0 - 330mm
urface finish :
Bright, Dull, HL(Hairline), others.
Description

Nimonic 80A Plates Sheets Strips Coils Nimonic 80a Heat Treatment Nimonic 80a Properties

Nickel Alloy 80A / Nimonic 80A
Technical Data Sheet

Chemical Composition Limits
Weight % Ni Cr Ti Al C Si Cu Fe Mn Co B Zr S
Alloy 80A Bal 18.0-21.0 1.8-2.7 1.0-1.8 0.10 max 1.0 max 0.2 max 3.0 max 1.0 max 2.0 max 0.008 max 0.15 max 0.015 max

Alloy 80A (Nimonic® alloy 80A) is a wrought, age-hardenable nickel-chromium alloy. Alloy 80A is similar to alloy 75 but made precipitation hardenable by additions of aluminium and titanium. Alloy 80A has good corrosion and oxidation resistance and high tensile and creep-rupture properties at temperatures to 815ºC (1500ºF). Vacuum refined versions are also available. Alloy 80A is used for gas-turbine components (blades, rings, discs), bolts, tube supports in nuclear generators, exhaust valves in internal combustion engines and has many other offshore/marine, automotive and electrical applications.

Typical Mechanical Properties

Material Condition Ultimate Tensile Strength ksi Yield Strength ksi Elongation on 4D (min) Hardness min
Alloy 80A Solution Annealed & Precipatation Treated (aged) 145 90 20 300 HV

Availability
Alloy 80A is available in Round Bar, Flat Bar, Rod, Tube, Plate, Sheet, Strip, Forging Stock and Wire. For all stock availability contact Sales.

Specifications

Alloy 80A Rod, Bar, Wire and Forging Stock BS 3076 HR1, ASTM B 637, AECMA PrEn2188, AECMA PrEn2189, AECMA PrEn 2190, AECMA PrEn 2396, AECMA PrEn2397, AIR 9165-37
Alloy 80A Plate, Sheet and Strip BS HR 201, AECMA PrEn2191
Alloy 80A Pipe and Tube BS HR 401
Alloy 80A Other BS HR 601, BS HR1, DIN 17742, AFNOR NC 20TA, UNS N07080, Werkstoff Nr 2.4952, Werkstoff Nr 2.4631, NIMONIC 80a (trademark), MSRR 7095 and MSRR 7011, MSRR 7013, HR201, HR401, HR601, NA20, VAT80A

Many sizes and forms available - Alloy 80A Bar, Alloy 80A Extruded Section, Alloy 80A Tube, Alloy 80A Plate, Alloy 80A Sheet, Alloy 80A Wire.

Disclaimer
Every effort is made to ensure that technical specifications are accurate. However, technical specifications included herein should be used as a guideline only. All specifications are subject to change without notice.

ABOUT ALLOY 80A

Alloy 80A demonstrates excellent corrosion resistance combined with high mechanical properties and creep resistance up to 815ºC. Good machineability and weldability make the alloy perfect for use in a variety of markets including Aerospace, Oil and Gas and Motorsport.

Alloy 80A can be used in a variety of applications, here are just a few examples:

  • Aircraft or marine turbine rotors
  • Exhaust valves
  • Diesel engine combustion chambers
  • High-strength fasteners

Nimonic 80A Plates Sheets Strips Coils Nimonic 80a Heat Treatment Nimonic 80a PropertiesNimonic 80A Plates Sheets Strips Coils Nimonic 80a Heat Treatment Nimonic 80a Properties
