Specifications
Brand Name :
Bao Steel
Model Number :
ASME SA515 GR 70
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
2Ton
Price :
785 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
500Tons
Delivery Time :
10 Days
Packaging Details :
Export Packing
Width :
1000-3500mm
Length :
2000-12000mm
Surface :
Black
Type :
Plate and Coil
Condition :
Hot Rolled
Supplementary Technology :
HIC Test
Description

ASME SA515 standard specification for pressure vessel plates, carbon steel, for intermediate-and higher-temperature service

ASME SA515 grade 70 plates shall be normalized.

Supplementary Technology: HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1
S5 | S6 | S7 | S8 | S9| S11 | S12 | S17

Thickness: 6MM to 300MM,

Width: 1500mm to 4050mm,

Length: 3000mm to 15000mm

Gangsteel is specialized in supplying ASME SA515 steel plate in SA515 grade 70. For more information of SA515 grade 70 steel plates, please check them in following:

SA515 grade 70 Chemical Composition
Grade The Element Max (%)
C Mn P S Si
SA515 grade 70 0.30-0.35 1.30 0.035 0.035 0.13-0.45

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

Grade SA515 grade 70 Mechanical Property
Thickness Yield Tensile Elongation
SA515 grade 70 mm Min Mpa Mpa Min %
200 260 485-620 17
50 21

Shipbuilding steel plate| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate

Equivalent steel grade of SA515 grade 70
Europe Belgium Germany France Italy Sweden UK Japan
KG,KW,KT W St E 315 A48 CP,AP,FP Fe 460-2-KW SS21,02,01 Gr 360,400

If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.

Main application of ASME SA515 Grade 70 are used to build boilers and pressure vessels such as petroleum, chemical industry, power plants.


Additional technical services for SA515 Gr.70 boiler steel plate from MITTEL which including Heat treatment(Normalized,TMCP,Quenched and Tempered,N+T),Z-test (Z15,Z25,Z35),Ultrasonic Examination,Low temperature impacting test,DWTT,PWHT and cutting&welding into special pieces for end users. Mill test certificate issued under EN 10204 format.


our advantage of supplying SA515/SA515M SA515 Grade 70 Pressure vessel steel plate I.Professional in steel knowledge for guanrantee steel property. II. Widest steel resources for accepting customers’ small orders. III. Closest relationships with china national mills for guanrantee delivery time and even delivery in advance.
