Specifications
Brand Name :
WU Steel
Model Number :
ASME SA516 GR 70
Certification :
SGS ISO
Place of Origin :
China
MOQ :
2 Tons
Price :
815 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
1000Tons
Delivery Time :
14 Days
Packaging Details :
Export Packing
Thickness :
3-150mm
Width :
1000-3000mm
Length :
2000-12000mm
Type :
Plate
Condtion :
Hot Rolled
Description

ASME SA516 GR 70 Plate Boiler and Pressure Vessel Hot Rolled Astm A516 Gr 70 Mechanical Specifications

ASME SA516 standard specification for pressure vessel plates, carbon steel for moderate and lower- temperature service.

ASME SA516 plates 40mm and under in thickness is normally supplied in the as-rolled condition. The plates may be ordered normalized or stress relieved, or both. ASME SA516 grade plates over 40mm in thickness shall be normalized.

Supplementary Technology: HIC Test | NACE MR0175 | Z15 | Z25 | Z35 | S1 | S2 | S3 | S4.1
S5 | S6 | S7 | S8 | S9| S11 | S12 | S14 | S17

Thickness: 6MM to 300MM,

Width: 1500mm to 4050mm,

Length: 3000mm to 15000mm

Gangsteel is specialized in supplying ASME SA516 steel plate in SA516 grade 70. For more information of SA516 grade 70 steel plates, please check them in following:

SA516 Grade 70 Chemical Composition

Grade

SA516 grade 70

 The Element Max (%)
C Si Mn P S
Thick <12.5mm 0.27 0.13-0.45 0.79-1.30 0.035 0.035
Thick12.5-50mm 0.28 0.13-0.45 0.79-1.30 0.035 0.035
Thick50-100mm 0.30 0.13-0.45 0.79-1.30 0.035 0.035
Thick100-200mm 0.31 0.13-0.45 0.79-1.30 0.035 0.035
Thick>200mm 0.31 0.13-0.45 0.79-1.30 0.035 0.035

Carbon Equivalent: Ceq = 【C+Mn/6+(Cr+Mo+V)/5+(Ni+Cu)/15】%

Grade SA516 Grade 70 Mechanical Property
Thickness Yield Tensile Elongation
SA516 grade 70 mm Min Mpa Mpa Min %
6-50 260 485-620 21%
50-200 260 485-620 17%

Shipbuilding steel plate| Alloy steel plates| High strength plate| Carbon steel plate| Stainless steel plate

Equivalent steel grade of SA516 grade 70
Europe Belgium Germany France Italy Sweden India Japan
E St E315 Fe 460-2-KG SS29,12,01

If you need more stock steel plates in pressure vessel steel plate, please click warehouse sizes.
