Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate
Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate
Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate
Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate
Specifications
Brand Name :
BAOSTEEL/TISCO
Model Number :
NM400 Class400
Certification :
ISO/SGS/BV
Place of Origin :
Jiangsu/China
MOQ :
1ton
Price :
USD2150 per ton
Payment Terms :
Western Union, T/T, L/C
Delivery Time :
within 10days after received the payment
Packaging Details :
Standard seaworthy packaging / as per buyer’s request
Grade :
NM400 Class400
Thickness :
3-100mm
Standard :
ASTM, AISI, DIN, EN, GB, JIS
Width :
1000-2000mm
Technique :
Cold Rolled Hot Rolled
Length :
as per customers' requiremen
Description

Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate

NM400 is a high-strength wear-resistant steel. NM400 has a very high mechanical strength; the mechanical properties of the common low-alloy steel plate 3 times to 5 times times; can significantly improve the wear resistance of associated components; thus improving the service life of the machine; reducing production costs. the product surface hardness is usually 360~450HB. Used in mining and construction machinery wear wearing parts machining and manufacturing application of structural steel.

NM400 is a kind of wear-resistant steel. NM-wear-resistant purpose of "resistance" and "grinding" first letters 400 Brinell hardness value of Hanyu Pinyin HB values. (400 hardness values in a broad sense, NM400 hardness range 360-420. )

Key words: Wear Plate,Wear-Resisting Plate,Wear Resistant Plate,Abrasion-Resistant Plate,Anti-Friction Plate.

  • Thickness: 6mm to60mm
  • Width: 1450mm to 2500mm,
  • Length: 3000mm to 10000mm
  • Any size is no problems. We can cut our plates for you.

More informations of our products

Products Abrasion Resistant steel plate / Wear Resistant Steel Plate
Thickness ≥6mm
Width 1.5~2.5m depend on requirement
Length cut to size according to your requirements
Grade 400 / 450 / 500 / 600
NM360 / NM400 / NM450 / NM500 / NR360 / NR400 / B-HARD360 / B-HARD400 / B-HARD450 / KN-55 / KN-60 / KN-63
XAR400 / XAR450 / XAR500 / XAR600 / Dillidur400 / Dillidur500
QUARD400 / QUARD450 / QUARD500
Payment term T/T, West Union, Escrow, L/C at sight
Tolerance Comply with standard or requirements
Heat Treatment Hot rolled, Annealing, Tempered
Packing Standard exporting packing or as requirements
Certificate ISO SGS BV
Application Widely used in petroleum industry, chemical industry, power station, boiler with making equipments or hardware like reactor, heat exchanger, seperator, sphere, liquid gas storage tank, nuclear-power reacto,pressure vessel, boiler drum, liquified petroleum gas pot, volute and so on.

Chemical of composition

Grade C Si Mn P S Cr Ni Mo B
NM360 ≤0.17 ≤0.50 ≤1.50 ≤0.025 ≤0.015 ≤0.70 ≤0.50 ≤0.40 ≤0.005
NM400 ≤0.24 ≤0.50 ≤1.60 ≤0.025 ≤0.015 0.40-0.80 0.20-0.50 0.20-0.50 ≤0.005
NM450 ≤0.26 ≤0.50 ≤1.60 ≤0.025 ≤0.015 ≤1.50 ≤1.00 ≤0.50 ≤0.004
NM500 ≤0.38 ≤0.50 ≤1.70 ≤0.020 ≤0.010 ≤1.20 ≤1.00 ≤0.65 0.005-0.006
400 ≤0.22 ≤0.70 ≤1.60 ≤0.025 ≤0.015 ≤0.80 ≤0.50 ≤0.25 ≤0.004
450 ≤0.25 ≤0.70 ≤1.60 ≤0.025 ≤0.010 ≤0.50 ≤0.25 ≤0.25 ≤0.004
500 ≤0.29 ≤0.70 ≤1.60 ≤0.025 ≤0.015 ≤1.00 ≤1.00 ≤0.60 ≤0.004

Grade Yield strength/MPa Tensile Strength /MPa Elongation A50/% Hardness HBW10/3000 Impact /J(-20°C) 90°Cold bending
NM360 900 1050 12 320-390 21 ≥3a
NM400 950 1200 12 380-430 21 D≥3a
NM450 1050 1250 7 420-480 21 D≥4.5a
NM500 1100 1350 6 470 17 D≥6a
NM550 - - - 530 - D≥6a

Features

  • Excellent Cold Bending & Welding Properties
  • Through Hardened for Long Wear Life
  • Flat Clean, Shot Blasted and Primed Finished Products
  • High Impact Properties
  • Grain-Refinen

FAQ:

Q1.Are you factory or trading company?

A1. We had our own cooperate fatory with good cooperation and long time(5 years) establish business .

Q2.How long have you been in this product?

A2:More than 8 years.

Q3. What's the minium quantity(MOQ)?

A3. 20 Metric tons

Q4. How long is shipping time?

A4. 7 (ready-made products)-10days(OEM)

Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate

Class400 Steel Plate 6.0*2000*6000mm Drilling AR400 Steel Plate
