2D SUS439 Ferritic Stainless cold roll steel sheets DIN1.4510 X3CrTi17
2D SUS439 Ferritic Stainless cold roll steel sheets DIN1.4510 X3CrTi17
2D SUS439 Ferritic Stainless cold roll steel sheets DIN1.4510 X3CrTi17
2D SUS439 Ferritic Stainless cold roll steel sheets DIN1.4510 X3CrTi17
Specifications
Brand Name :
BAO STEEL
Model Number :
439
Certification :
SGS ISO
Place of Origin :
China Wuxi
MOQ :
2 TONS
Price :
1650 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
500 tons
Delivery Time :
7 days
Packaging Details :
export packing
Grade :
439
Width :
1000-2000mm
Length :
2000-6000mm
Surface :
2D
Description

2D SUS439 Ferritic Stainless cold roll steel sheets DIN1.4510 X3CrTi17


SPECIFICATIONS

Material Ferrite stainless steel, magnetic.
Grade 409 / 410 / 430/439/441.436L
Standard AISI, ASTM, EN, GB, DIN, JIS
Thickness 0.17mm - 2.0mm (tolerances ±0.02mm)
Width 250mm - 850mm (tolerances ±6.00mm)
Pattern
Surface BA - processed with bright heat treatment after cold rolling.
2B - after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster.
2D – matt finish, best choice for deep drawing
Protection 1. Inter paper available
2. PVC protecting film available

The sizes or thicknesses of stainless steel can be customized, if you need additional information, please don’t hesitate to contact us at any time.
All standard products are supplied without inter paper & PVC film. If needed, please inform.


Chemical Composition and Mechanical properties 430Ti
Tensile strength:≥450 Yield strength :≥205 Elongation :≥22 Percentage of reduction of area:≥50 Hardeness :≤183HB

C :≤0.12, Si :≤1.00, Mn :≤1.25, P :≤0.060, S :≤0.030, Cr :16.00~18.00, Mo :≤0.60, Ni :≤0.60



SPECIFICATIONS:

Grade 430Ti
Ferrite stainless steel, magnetic.
Type Cold Rolled Stainless Steel Coils, Cold Rolled Stainless Steel Sheets
Brand BAOSTEEL, TISCO
Standard AISI, ASTM, EN, GB, DIN, JIS
Thickness 0.17mm - 2.0mm
Width 20-220mm, 220-600mm, 600-880mm
Weight 0.5-8 Metric Tons per coil, according to your request
Surface 2B--after cold rolling, by heat treatment, pickling or other equivalent treatment and lastly by cold rolling to given appropriate luster.
BA-- processed with bright heat treatment after cold rolling.
Service offered Cutting, Straighten, Pickling, Stamping circles
Package Standard export packing (Coil: waterproof paper + protective steel ring; Circle: wooden box), or as your requirement
Productivity 5000 Metric Tons per month
Payment Term

1. T/T, 30% before production, balances before delivery.
2. Irrevocable L/C at sight.

Ferritic Stainless Steels

  • Chromium is their major alloying element
  • Ductility and formability less than austenitic grades
  • Magnetic
  • Highly corrosion resistant, less durable than austenitic
  • Cannot be hardened by heat treatment
  • Contain between 10.5%-27% chromium and very little nickel
  • Common grades: part of the 400 series like 409, 410S, 430,430F

Fabrication process:

  • Plasma cutting (+/-1/32")
  • Oxyacetylene cutting (+/-1/16")
  • Laser cutting (+/-0.002")
  • Water Jet (+/-0.005")
  • Saws (+/-1/16")
  • Custom services: Pipe and Tube Bending, Punching, Welding, Angle Rolling (Max 6" x 6" X 1" leg out)
  • Any metals can be every shapes manufactured if you can draw, send it or fax to us, it is realiezed with our efforts.
  • 430Ti is in 430 steel and stainless steel cutting properties of the material. For automatic lathe, bolts and nuts, etc. 430 lx Ti and Nb is added in the 430 steel, to reduce the C content, improve the processing performance and welding performance. Used to heat water tank, heating water system, sanitary ware, family with durable appliance, bicycle flywheel, etc.
