ASTM A240-UNS S32750 Duplex Steel Plate, Cold Rolled / Hot Rolled Duplex Steel 2507 Plate

Quick Detail

2507 stainless steel plate

We can produce other size duplex stainless steel plate as customer required.

Description

Alloy 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and nitrogen levels provide excellent resistance to pitting, crevice, and general corrosion.

Standards
ASTM/ASME .......... A240 - UNS S32750
EURONORM............ 1.4410 - X2 Cr Ni MoN 25.7.4
AFNOR.................... Z3 CN 25.06 Az

Applications

• Oil and gas industry equipment
• Offshore platforms, heat exchangers, process and service water systems, fire-fighting systems, injection and ballast water systems
• Chemical process industries, heat exchangers, vessels, and piping
• Desalination plants, high pressure RO-plant and seawater piping
• Mechanical and structural components, high strength, corrosion-resistant parts
• Power industry FGD systems, utility and industrial scrubber systems, absorber towers, ducting, and piping

Specifications

Duplex Stainless Steel 2507

Duplex stainless steel 2507 provides outstanding resistance to chloride ion stress corrosion cracking, pitting and crevice corrosion. The alloy 2507 offers superior mechanical features. It is recommended for using at temperatures up to 600oF because above 600oF it losses hardness and corrosion resistance propertiess. It offers superior resistance to organic acids such as formic and acetic acid and inorganic acids. It is commonly used in marine operations, chemical processing, pulp and paper industry.

Chemical composition of Duplex stainless steel 2507 alloy

Physical Properties of Duplex stainless steel 2507 alloy

We manufacture Duplex stainless steel 2507 Alloy into the following product forms:

Duplex stainless steel 2507 Strip, Duplex stainless steel 2507 Sheet, Duplex stainless steel 2507 Plate Available Size:

Duplex stainless steel strip in coil form is available in lighter gauges up 24" wide.

Duplex stainless steel sheet is available in thicknesses ranging from 0.010’’ to 0.156". Standard Width & Length: 36" X 120" or 48" X 144", Cut to size available

Duplex stainless steelplate is available up 4" thick.
