DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate
Specifications
Brand Name :
TISCO BAOSTEEL JISCO
Model Number :
317L
Certification :
SGS
Place of Origin :
China(mainland)
MOQ :
2 Ton
Price :
2000-3000 USD/Ton
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
15000Tons
Delivery Time :
5-10 days
Packaging Details :
standard export seaworthy packing or as required
company type :
agent of TISCO
processing technology :
hot rolled
grade :
201 304 304L 316L 321 310S 317L 430 904L.etc
surface :
2B BA NO.4 NO.1 mirror 8K
standard :
GB JIS ASTM AISI EN DIN
tolerance :
0%-5%
thickness :
3.0-120mm
Description

DIN 1.4438 S31703 grade 317L Astm Stainless Steel Plate , Hot Rolled Polished SS Plate

Quick Detail
317L stainless steel plate

PRODUCTS

317L stainless steel plate

Brand

TISCO BAOSTEEL


size

1500x3000mm
1500x6000mm
Or as required


surface

original: NO.1
traetment: NO.4 mirror

thickness

3.0-120mm

Certificate

SGS, BV

grade 317L stainless steel plate
size: 1500 x 3000mm 1500 x 6000mm thickness: 3.0mm - 120mm
Brand: TISCO BAOSTEEL AUTO KUMPO
high quality and fast deliver
Description

About Our stainless steel plate

Width

1000mm-2600mm

Thickness

0.3mm-100mm

Length

As your requirements


Materials

303se,304,TP304,TP304L,305,306,309S,310S,310H, TP316,TP316L,316Ti
,317,317L,317Ti,321,SUS321,347,SUS347,440C,440F,C276,Ni80Cr20,Ti,630,
631,632,XM7,329JI,2205,2207,S32750,S32550,S32154,S32183, 904L,

Minimum order

1 Ton

Standards

ASTM A511 A269 A312 A213, GB/ T14976-2002 GB 13296-91

FOB Price

the latest price

Surface

polish, primary colour,matt,mirror face ,wire drawing

Productions requirement

cold drawing, cold rolling, precision rolling

Main markets

Asia,Europe,Middle-east area,Africa,South/North America

Certification

ISO

Application

chemical industry, metallurgy, construction, water conservancy


Feather and Applications
317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum austenitic stainless steel. It with conventional chrome - nickel austenitic stainless steel, such as, compared to 304 alloy has the stronger ability of resistance to chemical corrosion. In addition, compared with the conventional stainless steel, 317 l alloy has higher ductility, resistance to stress corrosion performance, compressive strength and resistance to high temperature performance. It is a low carbon level or L level, this level has during the welding and heat treatment process the sensitization effect of resistance.
Specifications

Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment.

SUS317L mechanical properties

YS (Mpa)TS (Mpa) EL (%) HV
>=176>=480>=40<=200

SUS317L chemical composition

CMnSiPSCr NiMo
<=0.030<=2.00 <=1.00 <=0.045<=0.030<= 18.0 ~ 20.0<= 11.0 ~ 15.0<=3.0 ~ 4.0


Density(g/cm3) : 7.93

Our Advantages:
1 More than 200 patterns
2 Bottom price
3 Reliable quality and service
4 Fast delivery

Welcome to inquiry. Looking forward to cooperating with you in the near future.
