Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Decorative Stainless Steel Welded Pipe High Polished
Specifications
Brand Name :
Mittel
Model Number :
304
Certification :
SGS,BV,ISO
Place of Origin :
China
MOQ :
5 Tons
Price :
2650 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
5000tons
Delivery Time :
10 days
Packaging Details :
export packing
OD :
19-219MM
Thickness :
0.5-4.0mm
Length :
6000mm
Surface :
400#,600#,800#
Shape :
Square
Welding Line Type :
ERW
Description

ASTM A554 A312 A213 A269 Decorative Stainless Steel Welded Pipe High Polished

Specifications

Square stainless steel pipe


1. Out size: 15*15-600*600
2. Wall thickness: 1.0-35.0MM
3. Certification: ISO, CE, JIS, EN10210

Welded Square Stainless Steel Pipe

1. STANDARD:

ASTM A554, A249, A269 and A270, A312

2. MATERIAL:

200 (Ni : 0.8%), 201B (Ni : 3%), 201H (Ni : 5%) 301 (Ni : 6%), 304, TP304, TP304L/304L, 321, TP321, 316, TP316L, 316L, 316Ti317, 317L, 309S, 310S(2520), 347, Duplex 2205, Duplex 2207, etc.

3. SURFACE:

180G, 320G, 400G Satin / Hairline

400G, 500G, 600G or 800G Mirror finish

4. TECHNIQUE:

Hot rolled, Cold rolled, ERW, High-frequency welded.

5. APPLICATION:

Decoration construction, upholstery, industry instrument

NAME

STAINLESS STEEL TUBE

PROCESS METHOD

COLD DRAWN AND COLD ROLLED

OUT SIZE

15*15-600*600MM

WALL THICKNESS

1.5-80MM

LENGTH

AS CUSTOMER REQUIRED

STEEL GRADE

200 (Ni : 0.8%), 201B (Ni : 3%), 201H (Ni : 5%) 301 (Ni : 6%), 304, TP304, TP304L/304L, 321, TP321, 316, TP316L, 316L, 316Ti317, 317L, 309S, 310S(2520), 347, Duplex 2205, Duplex 2207, etc.

PACKING
  1. PLASTIC CAP
  2. PLASTICE BAG WRAPPED OUTSIDE THE PIPE
  3. BUNDLES TO BE COVERED BY POLUTHENE AND STRAPPED SECURELY
  4. WOODEN BOX.

DELIVERY TIME

WITHIN 20 DAYS

PAYMENT TERMS

T/T, L/C

SHIPPING TERMS

FOB, CFR AND CIF

1) Application:Fluid,Oil,Construction
2) The best quality from TISCO
3) Certificate:BV,SGS
4) Low price and fast delivery

Stainless Steel Tube

We are specialized in selling seamless stainless steel tube/pipe.
Features:
1) Commodity: Seamless & welded austenitic stainless steel pipes/tubes
2) Process method: Cold drawn / cold rolled
3) Surface finish: Anneal / pickling / manual polished / mechanical polished
4) Material: TP304, TP304H, TP304LN, TP304L, TP310 / 310S, TP316L, TP316H, TP316 / 316L, TP317L, TP321 / 321H, TP347, S31803
5) Standards: ASTM A312 / 213 / 269 DIN17457 EN10216

6) Size:
A) NPS: 1 / 8" to 10"
B) Schedule: 5 / 5S, 10 / 10S, 20 / 20S, 40 / 40S, 80 / 80S, 120 / 120S, 160 / 160S, Acc. To ANSI B36.19 / 36.10
C) O. D.: 6mm to 219mm
D) W. T.: 0.5 to 25mm
7) Length: Max. 20 meters
8) Delivery conditions: Annealed and pickled
9) Applications: For fluid and gas transport, structure and Machining
10) Packing: Seaworthy wooden cases / steel framed cases / simple packaging
11) Certificate: ISO 9001: 2008, DNV, ASME, PED, TUV

Chemical Composition

GRADE

C

Si

Mn

P

S

Ni

Cr

Mo

YP(Mpa)

TS(Mpa)

EL(%)

MAX

MAX

MAX

MAX

MAX

MAX

MIN

MIN

MIN

316

0.08

0.75

2.00

0.045

0.03

11.00-14.00

16.00-18.00

2.00-3.00

205

515

40

GRADE

C

Si

Mn

P

S

Ni

Cr

Mo

YP(Mpa)

TS(Mpa)

EL(%)

MAX

MAX

MAX

MAX

MAX

MAX

MIN

MIN

MIN

316L

0.035

0.75

2.00

0.045

0.03

10.00-15.00

16.00-18.00

2.00-3.00

170

485

40

Product Information

Mirror Polished Stainless Steel Round Pipe

Name

Stainless Steel Seamless & Welded Tube &Pipe

Standard

ASTM A554, A249, A269 and A270

Material Grade

201: Ni 0.8%~1%

202: Ni 3.5%~4.5%

304: Ni 8%, Cr 18%

316: Ni 10%, Cr 18%

316L: Ni10%~14%

430: Cr16%~18%

Outer Diameter

48mm

Thickness

3mm

Length

6m or as customers' request

Tolerance

a) Outer Diameter: +/- 0.2mm

b) Thickness: +/- 0.02mm

c) Length: +/- 5mm

Surface

180G, 240G, 320G Satin / Hairline 400G, 600G Mirror finish

Application

handrail, railing, staircase, weld mesh screen, door, window, balcony, fence, bench, furniture, etc

Test

Squash test, extended test, water pressure test, crystal rot test, heat treatment, NDT

Chemical Composition of Material

Material Composition

201

202

304

316

316L

430

C

≤0.15

≤0.15

≤0.08

≤0.08

≤0.035

≤0.12

Si

≤1.00

≤1.00

≤1.00

≤1.00

≤1.00

≤1.00

Mn

5.5-7.5

7.5-10

≤2.00

≤2.00

≤2.00

≤1.00

P

≤0.06

≤0.06

≤0.045

≤0.045

≤0.045

≤0.040

S

≤0.03

≤0.03

≤0.030

≤0.030

≤0.030

≤0.030

Cr

13-15

14-17

18-20

16-18

16-18

16-18

Ni

0.7-1.1

3.5-4.5

8-10.5

10.0-14.0

10.0-14.0

**

Mo

**

**

**

**

2.0-3.0

**

Mechanical Property

Material Item

201

202

304

316

Tensile Strength

≥535

≥520

≥520

≥520

Yield Strength

≥245

≥205

≥205

≥205

Extension

≥30%

≥30%

≥35%

≥35%

Hardness (HV)

<105

<100

<90

<90

Decorative Stainless Steel Welded Pipe High PolishedDecorative Stainless Steel Welded Pipe High PolishedDecorative Stainless Steel Welded Pipe High PolishedDecorative Stainless Steel Welded Pipe High PolishedDecorative Stainless Steel Welded Pipe High Polished
