Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
Specifications
Brand Name :
MITTEL TISCO BAO STEEL
Model Number :
316LV 1.4441
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
300KGS
Price :
3.5 USD/KG
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
50000KGS
Delivery Time :
7 Days
Packaging Details :
Wooden Box
Type :
Round
Application :
Construction,decoration,Industry,Mechineal,shipbuilding
Standard :
ASTM,AISI
Grade :
300 Series
Shape :
Round
Dimensions :
5.5mm-500mm
Surface :
bright,Polished
Product name :
SS 201 304 316 410 420 2205 316L 310S Stainless Steel Round / flat Bar
Technique :
Cold Rolled Hot Rolled
Packing :
Standard Seaworthy Package
Price term :
CIF CFR FOB Ex-Work
Description

SS 316LVM / Din 1.4441 Grade Stainless Steel Round Bar (5-60mm) Tolerance - H9 Bright Finish

316LVM / 1.4441

Mittel steel with improved corrosion resistance compared to AISI 316L.

316LVM stainless steel or 1.4441 stainless steel (316L grade which confirms ISO 5832-1 norm) is a medical implant grade. This grade is written as 1.4441 or X2CrNiMo18-15-3 according to EN norm and it is written as UNS S31673 according to UNS norm. 316Lvm stainless steel is usually used inside the body parts. 316LVM stainless is bio-compatible stainless steel grade and 1.4441 grade can stay in side body for a very long time. 316LVM is also antimagnetic so this antimagnetic structure is very important for MRI machines. MRI machines works with extream magnetic fields and if any kind of material inside body is magnetic, then the machine can pull that magnetic part and this can cause injuries. 316LVM stainless steel is ready in Birçelik warehouse stocks and we only sell European Origin 1.4441 materials. 1.4441 stainless usually used in body part, prosthesis parts and dental parts.

Main fields of application of 1.4441

Osteosyntheses; bone screws, bone plates, marrow-nails. Also suitable for watch industry.

Chemical composition of 1.4441

C ≤ 0,030 Cr 17,0 - 19,0
Si ≤ 1,00 Mo 2,5 - 3,2
Mn ≤ 2,0 Ni 13,0 - 15,5
P ≤ 0,025 N ≤ 0,10
S ≤ 0,010 Fe rest`

Mechanical properties of 1.4441

annealed specification values (bars)
tensile strength Rm 490 - 690 MPa
elongation A ≥ 40%
cold worked specification values (bars)
tensile strength Rm 860 - 1100 MPa (higher values upon demand)
elongation A ≥ 12%

Sheets of 1.4441

dimensions kg/m2 tolerances
3,2 0,226 +0 / - 0.1 mm
4,5 1.013 +0 / - 0.1 mm

Bars of 1.4441

dimensions kg/m tolerances
6,0 0,22 h8
8,0 0,40 h8
12,7 1.01 h8

Further bars and profiles in different executions available upon request.

Delivery program

Various sizes and tolerances available upon request.

Services provided by our internal service center for 1.4441

We can provide various services directly in our service center. You save time, cost (internal or external) and don't need to find solutions for scrap management or handling of heavy plates and long bars.

Services suitable for sheets, plates, coils Services suitable for round bars
laser and waterjet cutting sawing of bars
shearing of sheets and plates bar marking
coil slitting turning machine

Din 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright FinishDin 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright FinishDin 1.4441 Grade Stainless Steel Round Bar SS 316LVM 5-60mm H9 Bright Finish
