AH36 DH36 EH36 High Tensile ABS Grade Shipbuilding Steel Plate Hot Rolled Low Temperature Steel Plate

Specifications

Brand Name :

Mittel

Model Number :

AH36/DH36/EH36

Certification :

SGS ISO MTC

Place of Origin :

China

MOQ :

5000KGS

Price :

0.85 USD/KG

Payment Terms :

L/C, T/T

Supply Ability :

80000KGS

Delivery Time :

7 Working Days

Packaging Details :

Wooden Pallet BOX

Grade :

AH36 DH36 EH36

Width :

10mm-3500mm

Length :

2000-12000mm

Thickness :

3-100mm

Condition :

Hot Rolled

Use :

Ship Building

Description

AH36 DH36 EH36 High Tensile ABS Grade Shipbuilding Steel Plate Hot Rolled Low Temperature Steel Plate

Name: AH36 DH36 EH36 High Tensile ABS Grade Shipbuilding Steel Plate Hot Rolled Low Temperature Steel Plate
Brand: Mittel
Price: 0.85 USD

DH36 shipbuilding steel plate is used for shipbuiling&platform.The shipbuilding steel plate grade DH36 is the high tensile strength steel.DH36 shipbuilding steel is the Hull structural steel,with it's good toughness properties, higher strength,strong corrosion-resistance,the processing properties,and welding properties.ASTM A131 DH36 steel plate can be used in the manufacture of the ship's hull structure whose weight is more than 10000 tons.

ABS DH36 Shipbuilding Steel Specification:
Thickness: 4mm to 260mm,
Width: 1200mm to 4000mm
Length: 3000mm to 18000mm.

ABS DH36 Shipbuilding Steel Application:
ABS DH36 Shipbuilding steel plates are mainly used for making the offshore oil drilling platform, the hull of ship building and ship repairing, the platform pipe joints and other components.

DH36 steel plate Chemical Composition %

Grade	C max	Si max	Mn	P max	S max	Als min	Ti max	Cu max	Cr max	Ni max	Mo max	Nb	V
DH36	0.18	0.50	0.90-1.60	0.035	0.035	0.015	0.02	0.35	0.20	0.40	0.08	0.02-0.05	0.05-0.10

Note: Generally speaking CE will be ≤ 0.40%. If the delivery condition is TMPC, the CE will be : ≤ 0.38% (thickness ≤ 50mm),≤0.40%( when the thickness >50-100). Ceq% =(C+Mn)/6+(Cr+Mo+V)/5+(Ni+Cu)/15.

DH36 steel plate Mechanical Property

Grade	Rm (MPa)	Re(MPa) min	A% min	Akv/J min
DH36	490-630	355	21	E.T °C	Thickness (mm)
				-20	≤ 50		>50-70		>70-100
					L	C	L	C	L	C
					34	24	41	27	50	34

Note: In the list , Rm: .tensile strength,Re: Yield strength,A%: elongation, E.T: experimental temperature,L: lengthways, C: crosswise.

DH36 steel plate Condition Of Delivery

Grade	Fine grains elements	category	The thickness of steel
			≤ 12	>12.5-20	>20-25	>25-35	>35-50	>50-100
DH36	Nb+V or V	Plate/ sheet	A(50)	N(50),CR(50),TM(50)				N(50),CR(25),TM(50)
		Profile steel		N(50),CR(50),TM(50),AR*(25)				-
	Al or Al+Ti	Plate/ sheet	A(50)		AR*(25)		-
					N(50),CR(50),TM(50)			N(50),CR(25),TM(50)
		Profile steel	A(50)	N(50),CR(50),TM(50),AR*(25)				-

Note: 1. delivery condition: A =Any ; N=Normalized ; CR=Control Rolled ; TM=TMPC, Temperature - deformation control rolling; AR= Can be hot rolled with the agreement of Classification Society ; CR=Can be control rolled with the agreement of Classification Society .
2. The Figure in the ( ) means the sampling volume to do the impact test, the unit is Ton.(-) means without impact test.

DH36 steel plate Contrast in the different standard

ASTM A131M	TOCT 5521	BS LR	GB712
DH36	D36	DH36	D36

AH36 DH36 EH36 High Tensile ABS Grade Shipbuilding Steel Plate Hot Rolled Low Temperature Steel Plate
