Specifications
Brand Name :
MITTEL
Model Number :
AH36
Certification :
SGS ISO MTC
Place of Origin :
China
MOQ :
2Ton
Price :
685 USD/Ton
Payment Terms :
L/C, T/T
Supply Ability :
50000KGS
Delivery Time :
14 DAYS
Packaging Details :
Wodden Pallet
Grade :
AH36
Width :
1000-2500mm
Length :
2000-12000mm
Thickness :
3-150mm
Use :
Ship Building
Classification :
CCS GL ABS LR DNV
Description

ABS AH36 shipbuilding Steel Description:
ABS AH36 steel is a kind of high tensile strength marine steel. All of these steels have been engineered to be optimal long-lived shipbuilding steels.As with other grades of steel, they have a specific gravity of 7.8. Higher-strength ABS shipbuilding steel comes in 12 grades of 3 strengths, AH36 is one of the grades. The ABS AH36 grades have yield strength of 51,000 psi (355 MPa), and ultimate tensile strength of 71,000 - 90,000 psi (490-620 MPa). All the ABS AH36 shipbuilding Steel offered by Katalor Industry can be certificated by American Bureau of Shipping(ABS) as per customer’s request.

ABS AH36 Shipbuilding Steel Application:
ABS AH36 Shipbuilding steel plates are mainly used for making the offshore oil drilling platform, the hull of ship building and ship repairing, the platform pipe joints and other components. ABS AH36 Shipbuilding steel plates also can be used for producing container and bulk cargo vessels as well as cruise ships, ferries and yachts.

ABS AH36 Steel Grade Specification:
Thickness: 4mm to 260mm,
Width: 1200mm to 4000mm
Length: 3000mm to 18000mm.

ABS AH36 Shipbuilding Steel Chemical Composition:

Grade C % Si % Mn % P % S % V % AL % Cr %
ABS Grade AH36 0.180 0.1-0.5 0.90-1.6 0.035 0.035 0.05-0.10 0.015 0.200
Cu % Mo % Nb % Ni % Ti %
0.350 0.080 0.02-0.05 0.400 0.020

ABS AH36 Grade Ship Steel Mechanical Properties:


Grade		 Thickness(mm) MinYield(Mpa) Tensile(Mpa) Elongation (%) Min Impact Energy
ABS Grade AH36 8mm-50mm Min 355Mpa 490-620Mpa 21% -0 34J
51mm-70mm Min 355Mpa 490-620Mpa 21% -0 41J
71mm-100mm Min 355Mpa 490-620Mpa 21% -0 50J
The min impact energy is longitudinal energy

our company is a professional steel company in manufacturing and exporting ABS AH36 shipbuilding steel plates and sheets.

Our ABS AH36 steel plates have been exported to worldwide shipyard and ship building company.

If you have any needs in ABS Grade AH36 steel plate price, please feel free to contact us.
